ProLiant DL160 Gen10 1p 4208 - 16GB-R - 8SFF
ITCurry #: 1171AHH1 | Article #: P19560-421-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Are you searching for a dense server with exceptional value to run on-premises and hybrid cloud solutions?
The secure 2P 1U HPE ProLiant DL160 Gen10 server delivers the right balance of performance, storage, reliability, manageability and efficiency in a dense and compact chassis, to meet the needs of growing businesses of a diverse set of customers – from SMB to service providers running wide range of workloads at a compelling price point.
What's new
- Enhanced iLO 5 security features such as iLO security dashboard and workload performance advisor.
- Available aggressively priced SMB offer models regionally released as “Smart Buy Express” in the U.S. and Canada, “Top Value” in Europe, and “Intelligent Buy” in Asia Pacific.
Features
Scalability and Efficiency in a Dense Design
- Supports Intel® Xeon® Scalable processors up to 8 cores and up to 85W.
- Deploy mid-level virtualization, IT/ web infrastructure for SMBs and small enterprises.
- Right balanced server to support multiple workloads.
Agile, Secure Infrastructure Management for Accelerating IT Service Delivery
- HPE iLO 5 enables the world’s most secure industry standard servers with HPE silicon root of trust technology to protect your servers from attacks, detect potential intrusions and recover your essential server firmware securely.
- New features include iLO Security Dashboard that helps detect and address possible security vulnerabilities and Workload Performance Advisor that provides server tuning recommendations for better server performance.
- Millions of lines of firmware code run before the server OS boots and with Runtime Firmware Verification, enabled by HPE iLO Advanced. The server firmware is checked every 24 hours verifying validity and credibility of essential system firmware.
- Secure Recovery allows server firmware to roll back to the last known good state or factory settings after detection of compromised code.
Industry-Leading Serviceability and Simplified Deployment
- HPE ProLiant DL160 Gen10 server comes with a complete set of services offered by HPE Pointnext, delivering confidence, reducing risk, and helping customers realize agility and stability.
- Services from HPE Pointnext simplify the stages of the IT journey. Advisory and Transformation Services professionals understand customer challenges and design an enhanced solution. Professional Services enables rapid deployment of solutions and Operational Services provides ongoing support.
- HPE IT investment solutions help you transform to a digital business with IT economics that align to your business goals.
| Processor | |
| Processor manufacturer | Intel |
| Processor generation | 2nd Generation Intel© Xeon© Scalable |
| Processor family | Intel Xeon Silver |
| Processor model | 4208 |
| Processor frequency | 2.1 GHz |
| Processor boost frequency | 3.2 GHz |
| Processor cores | 8 |
| Processor cache | 11 MB |
| Motherboard chipset | Intel C622 |
| Number of processors installed | 1 |
| Thermal Design Power (TDP) | 85 W |
| Processor cache type | L3 |
| Embedded options available | No |
| Scalability | 2S |
| Supported instruction sets | AVX-512 |
| Processor package size | 76.0 x 56.5 mm |
| Maximum number of PCI Express lanes | 48 |
| Execute Disable Bit | Yes |
| Memory clock speeds supported by processor | 2400 MHz |
| Memory types supported by processor | DDR4-SDRAM |
| Maximum internal memory supported by processor | 1.02 TB |
| Tcase | 78 øC |
| Processor codename | Cascade Lake |
| Processor operating modes | 64-bit |
| Processor threads | 16 |
| Processor lithography | 14 nm |
| Processor socket | LGA 3647 (Socket P) |
| Maximum number of SMP processors | 2 |
| Memory | |
| Internal memory | 16 GB |
| Internal memory type | DDR4-SDRAM |
| Memory slots | 16x DIMM |
| ECC | Yes |
| Memory clock speed | 2933 MHz |
| Memory layout (slots x size) | 1 x 16 GB |
| Maximum internal memory | 1.02 TB |
| Storage | |
| Maximum storage capacity | 20 TB |
| HDD interface | Serial ATA |
| Number of HDDs supported | 8 |
| Supported HDD sizes | 2.5" |
| RAID support | Yes |
| RAID levels | 0, 1, 5, 10 |
| Hot-Plug support | Yes |
| Optical drive type | No |
| Graphics | |
| On-board graphics card | Yes |
| Network | |
| Ethernet LAN | Yes |
| Ethernet interface type | Gigabit Ethernet |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 2 |
| VGA (D-Sub) ports quantity | 1 |
| Expansion slots | |
| PCI Express slots version | 3.0 |
| Design | |
| Chassis type | Rack (1U) |
| Product colour | Black, Silver |
| Rack mounting | Yes |
| Performance | |
| Remote administration | iLO 5 ASIC |
| Trusted Platform Module (TPM) | Yes |
| Software | |
| Operating system installed | No |
| Compatible operating systems | Windows Server 2016 Windows Server 2019 VMware ESXi 6.0 U3 VMware ESXi 6.5 U2 VMware ESXi 6.7 U1 Red Hat Enterprise Linux (RHEL) 7.6 (w/Kbase) SUSE Linux Enterprise Server (SLES) 12 SP4 SUSE Linux Enterprise Server (SLES) 15 |
| Processor special features | |
| Enhanced Intel SpeedStep Technology | Yes |
| Intel Virtualization Technology for Directed I/O (VT-d) | Yes |
| Intel© Hyper Threading Technology (Intel© HT Technology) | Yes |
| Intel© Turbo Boost Technology | 2.0 |
| Intel© AES New Instructions (Intel© AES-NI) | Yes |
| Intel Trusted Execution Technology | Yes |
| Intel VT-x with Extended Page Tables (EPT) | Yes |
| Intel TSX-NI | Yes |
| Intel 64 | Yes |
| Intel Virtualization Technology (VT-x) | Yes |
| Processor ARK ID | 193390 |
| Power | |
| Redundant power supply (RPS) support | Yes |
| Power supply | 800 W |
| Logistics data | |
| Harmonized System (HS) code | 84714100 |
| Sustainability | |
| Sustainability certificates | ENERGY STAR |
| Weight & dimensions | |
| Width | 434.6 mm |
| Depth | 614.9 mm |
| Height | 42.9 mm |
| Warranty | |
| Base Warranty | Non Non |
