Hci Server - Amd Barebone H252-z10 2u4n 4cpu 32xDIMM 24xHDD 4xPci-e 2x2200w
ITCurry #: 85365852 | Article #: 6NH252Z10MR-00-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Architecture for Modern Data Centers
AMD EPYC 7003 Series Processors – “Milan”
GIGABYTE servers and AMD EPYC 7003 Series Processors deliver the highest possible I/O throughput to pave the way for fast communication between CPU and accelerator in HPC and data analytics.
Max Memory Speed Even at 2 DPC
With GIGABYTE unique solution, maximum memory speed is now supported, even when using 2 DIMMS per channel. GIGABYTE’s server platforms give you the performance edge, with more memory capacity at faster speeds.
OCP 3.0 Ready
GIGABYTE’s G-,H-,R- series offer servers that feature an onboard OCP 3.0 slot for the next generation of PCIe 4.0 add on cards. Advantages of this new type include:
Easier Serviceability: simply slot in / pull out the card without needing to open the server chassis; tool less design
Larger Thermal Envelope: more space for heat sink provides an increased power budget for new & emerging capabilities
Hardware Security
Hardware-level Root of Trust
Protection is built in the silicon to ensure systems will not be vulnerable to security attacks or cyber threats. This hardware-level root of trust (ROT) helps isolate the system as the boot process starts to make sure a verified code is used.
Optional TPM 2.0 Module
For hardware-based authentication, the passwords, encryption keys, and digital certificates are stored in a TPM module to prevent unwanted users from gaining access to your data. GIGABYTE TPM modules come in either a Serial Peripheral Interface (SPI) or low pin count (LPC) interface.
CMC for Chassis Management & Multi-Node Monitoring
GIGABYTE’s H-Series Servers feature a Chassis Management Controller (CMC) for chassis-level management and node-level monitoring by connecting nodes internally via BMC chips integrated on each node. Resulting in only one mLAN connection required to perform monitoring of all four nodes, and results in less Top-of-Rack (ToR) cabling and switch connections.
Multi-Server Management
GIGABYTE’s H-Series Servers also feature the ability to create a “ring” connection for monitoring & management of all servers in a rack for greater cost savings and management efficiency.
Power Efficiency
Automatic Fan Speed Control
GIGABYTE servers are enabled with Automatic Fan Speed Control to achieve the best cooling and power efficiency. Individual fan speeds will be automatically adjusted according to temperature sensors strategically placed in the servers.
Cold Redundancy
To take advantage of the fact that a PSU will run at greater power efficiency with a higher load, GIGABYTE has introduced a power management feature called Cold Redundancy for servers with N+1 power supplies. When the total system load falls lower than 40%, the system will automatically place one PSU into standby mode, and results of 10% improvement in efficiency.
High Availability
Smart Crises Management and Protection (SCMP)
SCMP is a GIGABYTE patented feature which is deployed in servers with non-fully redundant PSU design. With SCMP, in the event of faulty PSU or overheated system, the system will force the CPU into an ultra-low power mode that reduces the power load, which prevents the system from unexpected shutdown and avoids component damage or data loss.
Dual ROM Architecture
If the ROM that stores the BMC and BIOS fails to boot, the system will reboot with the backup BMC and/or BIOS replacing the primary. Once the primary BMC is updated, the ROM of the backup BMC will automatically update the backup through synchronization. For the BIOS, it can be updated based on user's choice of firmware version.
Value-added Management
GIGABYTE offers free-of-charge management applications via a specialized small processor built on the server.
GIGABYTE Management Console
For management and maintenance of a server or a small cluster, users can use the GIGABYTE Management Console, which is pre-installed on each server. Once the servers are running, IT staff can perform real-time health monitoring and management on each server through the browser-based graphical user interface.
GIGABYTE Server Management (GSM)
GSM is a software suite that can manage clusters of servers simultaneously over the internet. GSM can be run on all GIGABYTE servers and has support for Windows and Linux. GSM can be downloaded from GIGABYTE website and complies with IPMI and Redfish standards.
Certified Ready with Software Partners
Being a member of key software alliance partner programs enables GIGABYTE to together rapidly develop and validate joint solutions, enabling our customers to modernize their data centers and implement IT infrastructure and application services with speed, agility, and cost optimization. GIGABYTE servers have a compatibility across various ecosystems.
Processor | |
Built-in processor | No |
Processor socket | Socket SP3 |
Processor manufacturer | AMD |
Processor family | AMD |
Number of processors supported | 4 |
Compatible processor series | AMD EPYC |
Memory | |
Number of DIMM slots | 32 |
Supported memory types | DDR4-SDRAM |
Maximum RDIMM memory | 128 GB |
Supported RDIMM clock speeds | 3200 MHz |
Memory channels | Octa-channel |
Storage | |
Number of storage drives supported | 24 |
Hot-swap HDD bays | Yes |
Number of 2.5" bays | 24 |
Storage drive sizes supported | 2.5" |
Graphics | |
On-board graphics card model | Aspeed AST2500 |
Network | |
Ethernet LAN | Yes |
Ethernet interface type | Gigabit Ethernet |
Ethernet LAN data rates | 1000 Mbit/s |
LAN controller | Intel© I350-AM2 |
Ports & interfaces | |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 8 |
Ethernet LAN (RJ-45) ports | 8 |
VGA (D-Sub) ports quantity | 4 |
Expansion slots | |
PCI Express slots version | 3.0, 4.0 |
PCI Express x16 (Gen 3.x) slots | 4 |
Number of M.2 (M) slots | 8 |
Features | |
Trusted Platform Module (TPM) | Yes |
Logistics data | |
Harmonized System (HS) code | 84714100 |
Design | |
Chassis type | Rack (2U) |
Product colour | Black, Steel |
LED indicators | Power, Status |
Rack rails | Yes |
Cooling type | Active |
Heat sink included | Yes |
Number of fans | 8 fan(s) |
Fan diameter | 8 cm |
Power | |
Redundant power supply (RPS) support | Yes |
Number of redundant power supplies supported | 2 |
Number of redundant power supplies installed | 2 |
80 PLUS certification | 80 PLUS Platinum |
Operational conditions | |
Operating temperature (T-T) | 10 - 35 øC |
Storage temperature (T-T) | -40 - 60 øC |
Operating relative humidity (H-H) | 8 - 80% |
Storage relative humidity (H-H) | 20 - 95% |
Weight & dimensions | |
Width | 440 mm |
Depth | 695 mm |
Height | 87.5 mm |
Packaging data | |
Packaging content | 1 x H252-Z10 4 x CPU heatsinks 1 x Rail Kit |
Package width | 1167 mm |
Package depth | 700 mm |
Package height | 309 mm |
Warranty | |
Base Warranty | Non Non |
