Lq-780 - Dot Matrix Printer 24 Pin - A4 - USB
ITCurry #: 1925Y675 | Article #: C11CJ81401-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Fast and reliable dot matrix printing with the Epson LQ-780. Its robust nature and modern design fits comfortably into any environment.
Designed with productivity in mind, the LQ-780 is an ultra-reliable dot matrix printer that offers an impressive ribbon yield. It is fast and compact with a robust build. Its modern design allows effortless integration into any work environment, be it an office or a warehouse.
Fast printing:
Print faster and more productively. The LQ-780 prints the original + six copies, and is capable of printing an impressive 487 cps (10 cpi) when using printer resident fonts.
High ribbon yield:
In a demanding and fast-moving work environment a high ribbon yield is essential, and with 10 million characters per ribbon, this marks the LQ-780 as a leading force in the flatbed market. It is also cost-effective, with long ribbon replacement cycles, low running costs and total cost of ownership.
Dependable:
Durable and built to last, users will be assured by the MTBF (mean time between failures) of 20,000 power on hours. The robust casing can stand up to high humid and heat conditions, and automatic paper thickness adjustment makes the LQ-780 intuitive to use. This results in greater productivity and less maintenance from down time - essential when producing large amounts of documents and data.
Smart design:
This compact hard-working printer is designed to fit on your desk. With its modern, black and white casing, it blends in seamlessly in both office and warehouse environments.
| Printing | |
| Maximum resolution | 360 x 180 DPI |
| Maximum printing width (columns) | 106 |
| Colour | No |
| Maximum print speed | 487 cps |
| Maximum print speed (draft) | 487 cps |
| Maximum print speed (LQ) | 366 cps |
| Maximum number of copies | 6 copies |
| Built-in barcodes | CODABAR (NW-7), Code 128 (A/B/C), Code 39, EAN13, EAN8, Industrial 2/5, Interleaved 2/5, Matrix 2/5, POSTNET, UPC-A, UPC-E |
| Number of barcode fonts | 8 |
| Number of bitmap fonts | 11 |
| Bitmap fonts | Courier, Draft, Prestige, Roman |
| Number of scalable fonts | 4 |
| Scalable fonts | Roman, Roman T, Sans Serif, Sans Serif H |
| Character sets | PC437, PC850, PC858, ISO 8859-15, Roman 8, Italic |
| Number of characters | 15 |
| Paper handling | |
| Paper tray media types | Envelopes |
| Continuous paper thickness range | 0.12 - 0.49 mm |
| Multi-part paper thickness range | 0.12 - 0.49 mm |
| Single sheet thickness range | 0.065 - 0.15 mm |
| Features | |
| Product colour | Black, White |
| Buffer size | 64 KB |
| Sound pressure level (printing) | 59 dB |
| Country of origin | Indonesia |
| Ports & interfaces | |
| Standard interfaces | Parallel, USB 2.0 |
| Endurance | |
| Print head | 24-pin |
| Print head life | 400 million characters |
| Mean time between failures (MTBF) | 35000 h |
| Power | |
| Power consumption (typical) | 46 W |
| Power consumption (standby) | 8.3 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 35 øC |
| Operating relative humidity (H-H) | 10 - 80% |
| System requirements | |
| Windows operating systems supported | Windows 11 x64 |
| Server operating systems supported | Windows Server 2003, Windows Server 2022 |
| Weight & dimensions | |
| Width | 480 mm |
| Depth | 301 mm |
| Height | 211 mm |
| Weight | 6.7 kg |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Package width | 325 mm |
| Package depth | 590 mm |
| Package height | 350 mm |
| Package weight | 8.28 kg |
| Other features | |
| Print technology | Dot matrix |
| Needles | 24 |
| Logistics data | |
| Products per pallet | 24 pc(s) |
| Products per pallet (UK) | 36 pc(s) |
| Harmonized System (HS) code | 84433210 |
| Warranty | |
| Base Warranty | Non Non |
