Lq-2090ii - Dot Matrix Printer - Dot Matrix - A4 - USB / Parallel
ITCurry #: 1925V817 | Article #: C11CF40401-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Network dot matrix printer
Fast, networked 24-pin, 136-column dot matrix printer that offers outstanding reliability and an extremely low TCO.
The LQ-2090II is a high-volume dot matrix printer designed for fast and reliable printing. Upgrade your existing dot matrix printers to our latest model, which is now Energy Star compliant, and delivers built-in network capability with an incredibly low TCO.
Fast print speed
The LQ-2090II offers an improved USD (ultra speed draft) speed of 550 characters per second at 10 characters per inch, making a real difference to high-volume print runs such as stock reports and large batches of invoices or freight documents.
Increased reliability
Epson's dot matrix technology is already mature and very reliable. Building on this, the new printer improves the mean time between failure by 25% to 25,000 power-on hours, ideal for challenging conditions or where regular maintenance is not practical.
Same consumables
This printer uses the same ribbons as existing models, so you can upgrade your hardware and continue to use your current ribbon supplies.
| Printing | |
| Maximum printing width (columns) | 136 |
| Colour | No |
| Maximum print speed | 550 cps |
| Character pitch | 10 cpi |
| Maximum number of copies | 6 copies |
| Built-in barcodes | Code 128 (A/B/C), Code 39, EAN13, EAN8, Interleaved 2/5, POSTNET, UPC-A, UPC-E |
| Paper handling | |
| Paper tray media types | Envelopes |
| Continuous paper thickness range | 0.12 - 0.46 mm |
| Label thickness range | 0.16 - 0.19 mm |
| Multi-part paper thickness range | 0.12 - 0.46 mm |
| Single sheet thickness range | 0.065 - 0.14 mm |
| Features | |
| Product colour | Black |
| Buffer size | 128 KB |
| Sound pressure level (printing) | 55 dB |
| Country of origin | Indonesia |
| Ports & interfaces | |
| Standard interfaces | Parallel, USB 2.0 |
| Endurance | |
| Print head | 24-pin |
| Print head life | 400 million characters |
| Mean time between failures (MTBF) | 25000 h |
| Power | |
| Power consumption (typical) | 49 W |
| Power consumption (standby) | 49 W |
| Power consumption (economy mode) | 49 W |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 35 øC |
| Operating relative humidity (H-H) | 10 - 80% |
| System requirements | |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows Vista, Windows XP |
| Server operating systems supported | Windows Server 2003 x64, Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2016 |
| Mac compatibility | No |
| Weight & dimensions | |
| Width | 612 mm |
| Depth | 375 mm |
| Height | 177 mm |
| Weight | 9.4 kg |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Package width | 451 mm |
| Package depth | 735 mm |
| Package height | 295 mm |
| Package weight | 12.2 kg |
| Other features | |
| Print technology | Dot matrix |
| Needles | 24 |
| Compatible operating systems | Windows 10, Windows 7, Windows 7, 64-Bit-Version, Windows 8, Windows 8.1, Windows 8.1 x64 Edition, Windows Server 2003 x64, Windows Server 2008 R2, Windows Server 2012 R2, Windows Server 2016, Windows Vista, Windows Vista, 64-Bit-Version, Windows XP, Windows XP Professional x64 Edition SP2 or later |
| Technical details | |
| Sustainability certificates | ENERGY STAR |
| Warranty | |
| Base Warranty | Non Non |
| Logistics data | |
| Products per pallet | 14 pc(s) |
| Pallet gross length | 120 cm |
| Pallet gross width | 80 cm |
| Pallet gross height | 4.59 m |
| Products per pallet layer | 2 pc(s) |
| Products per pallet layer (UK) | 3 pc(s) |
| Products per pallet (UK) | 21 pc(s) |
| Pallet length (UK) | 120 cm |
| Pallet width (UK) | 100 cm |
| Pallet height (UK) | 4.59 m |
| Harmonized System (HS) code | 84433210 |
