Touchcomputer Ids 7001l Core i5 (3.6 GHz) 4GB 320GB No O/s
ITCurry #: M0133034 | Article #: E272400-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
ECMG2 Computer Modules (for IDS -01 Series Displays)
The Elo Interactive Digital Signage (IDS) touch platform enables increased customer engagement and immersive brand experiences by adding an exciting new dimension to traditional broadcast digital signage - the power of touch. Elo's ECMG2 computer modules, available for use with the Elo 3201L, 4201L, 5501L and 7001L IDS touchscreens are well-suited for interactive media delivery and online collaboration for modern office environments. The computer modules are easily installed into the IDS display – avoiding costs of in-wall installation of a traditional player or PC. Computer modules are available in a choice of two models: ECMG2-i3 based on a 3.3GHz Intel® Core i3 processor and HD2500 graphics; and ECMG2-i5 based on a 3.6GHz Intel® Core i5 processor and HD4000 graphics.
Centralized management and security capabilities of Microsoft® Windows® ensures compatibility with many content management servers and web-based consoles for seamless connection with the internet, digital marketing, interactive whiteboard, building directory, virtual receptionist, and point-of-information (POI) applications.
The ECMG2 computer modules can support optimal partitioning of locally cached and network stored content, allowing developers to monitor and deploy content via device-to-device or web connections.
| Processor | |
| Processor frequency | 3.3 GHz |
| Processor family | Intel© CoreT i5 |
| Processor generation | 3rd gen Intel© CoreT i5 |
| Processor model | i5-3475S |
| Processor cores | 4 |
| L3 cache | 6 MB |
| Motherboard chipset | Intel© H61 Express |
| Memory | |
| Internal memory | 4 GB |
| Internal memory type | DDR3-SDRAM |
| Memory slots | 2x SO-DIMM |
| Memory layout (slots x size) | 1 x 4 GB |
| Maximum internal memory | 8 GB |
| Storage | |
| Total storage capacity | 320 GB |
| Storage media | HDD |
| Storage drive interface | Serial ATA |
| Storage drive size | 2.5" |
| Card reader integrated | No |
| Graphics | |
| On-board graphics card model | Intel© HD Graphics 4000 |
| Network | |
| Wi-Fi | No |
| Ethernet LAN | Yes |
| Cabling technology | 10/100/1000Base-T(X) |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| USB 2.0 ports quantity | 4 |
| Microphone in | Yes |
| Headphone outputs | 1 |
| Design | |
| Rack mounting | No |
| Product colour | Black |
| Display | |
| Display included | No |
| Software | |
| Operating system installed | No |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 øC |
| Storage temperature (T-T) | -20 - 60 øC |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 5 - 95% |
| Certificates | |
| Certification | US UL, FCC, cUL, IC, CE, VCCI, BSMI, KC, CB |
| Weight & dimensions | |
| Width | 274 mm |
| Depth | 248 mm |
| Height | 45.7 mm |
| Weight | 2.03 kg |
| Packaging data | |
| Package width | 392 mm |
| Package depth | 362 mm |
| Package height | 130 mm |
| Package weight | 2.9 kg |
| Warranty | |
| Base Warranty | Non Non |
| Other features | |
| Battery technology | Lithium-Ion (Li-Ion) |
