LCD Monitor 1717l - 17in - Intellitouch Anti-glare Black
ITCurry #: M0133358 | Article #: E017030
Related products
Product Information
The 1717L touchmonitor is built to withstand the rigors of continuous public use with a rugged "built for touch" design. Its stylish, thin and modern look is coupled with a retail-focused feature set and is an attractive solution for commercial touchmonitor needs. It is well suited for high use public venues where point-of-sale, point-of-information, point-of-service, shelf-level and countertop interactive digital signage and loyalty systems systems are found.
The 1717L is offered with AccuTouch five-wire resistive technology, IntelliTouch surface acoustic wave, or iTouch pure glass surface acoustic wave technology. AccuTouch is widely used in retail and hospitality environments based on its proven ability to survive splashing liquids, food and grease. IntelliTouch and iTouch pure glass surface acoustic wave technology delivers the ultimate in optical quality for dry retail and hospitality applications.
The optional 3-track magnetic stripe reader (MSR), programmable to either HID or Keyboard Emulation, is easily installed by the user, providing an elegant, integrated solution and eliminating the need for external brackets or attachments.
The 1717L touchmonitor is environmentally friendly, lightweight and uses less power with state-of-the-art LED backlights in the display panel.
- Sleek and thin design with “Built for Touch” Reliability.
- Flexible and space-saving.
- 40% Energy savings using LED technology.
- Zero-bezel touchscreen versions for a smooth, easy-to-clean surface.
- Antiglare or Clear glass.
- Removable base and mounting options including VESA, wall and pole-mounting for installation flexibility and capped through-mount holes on base for table-top security.
- 17” diagonal active matrix TFT LED-backlit LCD.
- Active Display Area: 13.3 x 10.6 inches/338 x 270 mm.
- 5:4 aspect ratio.
- 1280 x 1024 native resolution. Other resolutions supported.
- USB and RS232 serial connections.
- Touch technology: AccuTouch (single- touch), IntelliTouch (single-touch) and iTouch (single-touch).
- Typical power consumption: 20W, internal and external power options.
| Display | |
| Display diagonal | 43.2 cm (17") |
| Display resolution | 1280 x 1024 pixels |
| Native aspect ratio | 5:4 |
| Display technology | LCD |
| Touchscreen | Y |
| Touchscreen type | Tabletop |
| Response time | 5 ms |
| Screen shape | Flat |
| Supported graphics resolutions | 720 x 400, 1024 x 768 (XGA), 1280 x 1024 (SXGA), 640 x 480 (VGA), 800 x 600 (SVGA) |
| Aspect ratio | 5:4 |
| Contrast ratio (typical) | 800:1 |
| Viewing angle, horizontal | 170ø |
| Viewing angle, vertical | 160ø |
| Display number of colours | 16.78 million colours |
| Horizontal scan range | 31.5 - 80 kHz |
| Vertical scan range | 56 - 75 Hz |
| Display brightness | 225 cd/mý |
| LED backlight | Y |
| Performance | |
| NVIDIA G-SYNC | N |
| AMD FreeSync | N |
| Design | |
| Product colour | Black |
| Glass thickness | 4.3 cm |
| Ports & interfaces | |
| Number of upstream ports | 1 |
| VGA (D-Sub) ports quantity | 1 |
| RS-232 ports | 1 |
| Warranty | |
| Base Warranty | Non Non |
| Ergonomics | |
| Panel mounting interface | 75 x 75 mm |
| On Screen Display (OSD) languages | Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese |
| Number of OSD languages | 8 |
| Power | |
| Power consumption (typical) | 20 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Power supply type | AC/DC |
| Voltage tolerance | 5% |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 øC |
| Storage temperature (T-T) | -20 - 60 øC |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 10 - 90% |
| Weight & dimensions | |
| Width (with stand) | 392 mm |
| Depth (with stand) | 215 mm |
| Height (with stand) | 361 mm |
| Weight (with stand) | 5.4 kg |
| Packaging data | |
| Package width | 511 mm |
| Package depth | 233 mm |
| Package height | 510 mm |
| Package weight | 8.3 kg |
| Logistics data | |
| Harmonized System (HS) code | 85285210 |
| Other features | |
| Dimensions (W x D x H) with stand | 392 x 215 x 361 mm |
| Display viewable area (HxV) | 338 x 270 mm |
| Mean time between failures (MTBF) | 50000 h |
