TRIPP LITE SmartRack 6U Low-Profile Vertical-Mount Server-Depth Wall-Mount Rack Enclosure Cabinet
ITCurry #: 57904531 | Article #: SRWF6U36-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
The SRWF6U36 SmartRack 6U Low-Profile Vertical-Mount Server-Depth Wall-Mount Rack Enclosure Cabinet is designed to house EIA-standard 19-inch rack equipment in network wiring closets, retail locations, classrooms, back offices and other areas with limited floor space where you need equipment to be secure, organized and out of the way. Constructed from heavy-duty steel with a durable black powder-coated finish, the cabinet has a maximum load capacity of 150 lbs (68 kgs).
Because the low-profile cabinet mounts vertically, it extends less than 12 inches from the wall while housing equipment up to 36 inches deep, including 1U servers, UPS systems, battery packs and switches. In addition to 6U of rack space in the primary mounting area, it also includes a slide-out 2U mounting bracket at the top of the enclosure for patch panels up to 2.5 inches deep.
The top panel and front door lock securely to help prevent damage, tampering or theft. The cabinet is vented, which allows air to flow freely and keep equipment cool. The reversible front door can open left or right. Convenient top and bottom ports allow easy cable routing.
The SRWF6U36 comes fully assembled and ready to mount to the wall. Equipment installation is easy with threaded mounting holes and hardware that support M6 or 12-24 mounting.
| Features | |
| Product colour | Black |
| Housing material | Steel |
| Maximum weight capacity | 68 kg |
| Rack capacity | 6U |
| Certification | EIA-310-E |
| Country of origin | China |
| Weight & dimensions | |
| Size (imperial) | 48.3 cm (19") |
| Width | 650.2 mm |
| Depth | 292.1 mm |
| Height | 1092.2 mm |
| Weight | 39.5 kg |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Package width | 812.8 mm |
| Package depth | 1244.6 mm |
| Package height | 457.2 mm |
| Package weight | 39.5 kg |
| Packaging content | |
| Mounting kit | Yes |
| Screws included | Yes |
| Technical details | |
| Sustainability certificates | RoHS |
| Compliance certificates | RoHS |
| Logistics data | |
| Products per pallet | 1 pc(s) |
| Master (outer) case width | 812.8 mm |
| Master (outer) case length | 1244.6 mm |
| Master (outer) case height | 457.2 mm |
| Master (outer) case gross weight | 39.5 kg |
| Products per master (outer) case | 1 pc(s) |
| Harmonized System (HS) code | 8517.79.0000 |
| Warranty | |
| Base Warranty | Non Non |
