TRIPP LITE MTP/MPO (APC) to 8xLC (UPC) Singlemode Breakout Patch Cable, 40/100 GbE, QSFP+ 40GBASE-PLR4, Plenum, Yellow, 1 m (3.3 ft.)
ITCurry #: 57905799 | Article #: N390-01M-8LC-AP-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
9/125 Rated Singlemode Cable for 40/100 Gb Ethernet Applications
Designed for high-density fiber patching between data center MDFs and IDFs in enterprise installations
Optimized for QSFP+ 40GBASE-PLR4 and QSFP28 100GBASE-PSM4 networks
Plenum-rated jacket suited for ceilings, walls and ducts
Yellow-colored for identification as a singlemode cable
MTP/MPO APC and LC Duplex UPC Connectors with Push/Pull Tabs
MTP/MPO female connector and 8 LC duplex male connectors—no splicing required
12-fiber MTP/MPO connector 12 times denser than SC connector
APC connector angled to prevent light from reflecting back into laser
UPC connector with premium-grade ceramic ferrule for 10 GbE and faster applications
Push/pull tabs easy to install and remove with one hand
Error-Free Signal Transfer
Fully transmits 40GBASE-PLR4 with 4 fibers transmitting at 10 Gbps in each direction
100% tested for low insertion loss and back reflection
Slim, space-saving uniboot design easier to manage in crowded applications
| Features | |
| Cable length | 3 m |
| Connector 1 | MPO/MTP |
| Connector 2 | LC |
| Connector 1 gender | Male |
| Connector 2 gender | Female |
| Cable type | OFNP |
| Product colour | Aqua colour |
| Fiber mode structure | Multi-mode |
| Data transfer rate | 100 Gbit/s |
| Certificates | |
| Compliance certificates | RoHS |
| Packaging data | |
| Package width | 177.8 mm |
| Package depth | 12.7 mm |
| Package height | 228.6 mm |
| Package weight | 60 g |
| Logistics data | |
| Master (outer) case GTIN (EAN/UPC) | 10037332205411 |
| Country of origin | China |
| Master (outer) case width | 185.4 mm |
| Harmonized System (HS) code | 8544.70.0000 |
| Master (outer) case length | 149.9 mm |
| Master (outer) case height | 101.6 mm |
| Master (outer) case gross weight | 690 g |
| Products per master (outer) case | 10 pc(s) |
| Warranty | |
| Base Warranty | Non Non |
