KVM Switch, 2 Port, Dual Display, 4K, HDMI
ITCurry #: M9238177 | Article #: DS-12860-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Operate 2 PCs with dual display using a USB keyboard and mouse combination – switch between two computers by pressing a button
- Use two monitors, one mouse / keyboard to operate 2 computers with dual display
- Supports a maximum UHD resolution of 4K / 30 Hz + FreeSync
- USB ports for mouse and keyboard
- Audio connections for microphone / speakers, supports Dolby True HD and DTS HD Master Audio
- Integrated USB hub with USB A port for additional peripheral devices
- Switching between the PCs via switch on the KVM switch or hotkey on the keyboard
- LED status and function indicators on the front + OSD display
- No more time-consuming re-plugging of connection cables necessary
- True plug and play - no software or driver installation required (BIOS hardware connection)
- Robust metal housing
With the DIGITUS® 2-Port KVM Switch for dual displays, you can operate two 4k-compatible PCs using a single USB keyboard and mouse combination. By pressing a button or hot key, you can switch comfortably between the two PCs and are spared the trouble of replugging all cables. Output on up to two monitors is provided via two HDMI® outputs on the rear side. You can also switch between the audio signals for the microphone and speaker. In addition, a USB port is included on the front side for use with other peripheral devices like USB sticks or external hard drives on both PCs. The connected peripheral devices are each assigned to the active PC. Status LEDs on the front side of the switch show you the current configuration at all times. The slim switch features the added benefits of sturdy metal housing.
| Ports & interfaces | |
| Number of computers controlled | 2 |
| Keyboard port type | USB |
| Mouse port type | USB |
| Video port type | HDMI |
| HDMI ports quantity | 6 |
| HDMI version | 1.4b |
| Console ports | USB A |
| Console USB ports quantity | 2 |
| USB connector type | USB Type-A, USB Type-B |
| Audio connections | Yes |
| DC-in jack | Yes |
| Performance | |
| HD type | 4K Ultra HD |
| Maximum resolution | 3840 x 2160 pixels |
| Video bandwidth | 30 Hz |
| Design | |
| Rack mounting | No |
| Product colour | Black |
| Housing material | Metal |
| LED indicators | Status |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 80 øC |
| Storage temperature (T-T) | -20 - 60 øC |
| Operating relative humidity (H-H) | 0 - 80% |
| Weight & dimensions | |
| Width | 132 mm |
| Depth | 92 mm |
| Height | 66 mm |
| Weight | 575 g |
| Packaging content | |
| Cables included | HDMI, KVM |
| Quick installation guide | Yes |
| AC adapter included | Yes |
| Logistics data | |
| Harmonized System (HS) code | 85176200 |
| Country of origin | China |
| Warranty | |
| Base Warranty | Non Non |
