HDMI AOC hybrid-fiber connection cable, Type A M/M, 10m UHD 8K@60Hz, CE, black
ITCurry #: M9238164 | Article #: AK-330126-100-S-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
This active HDMI® AOC Hybrid Fiber Optic Cable is ideally suited for transferring uncompressed video and audio data with high bandwidth over longer distances. The hybrid construction, which uses copper and fiber optic cable, prevents electromagnetic interference. This ensures a loss-free transfer along the entire length of the cable with UHD resolution of up to 8K/60Hz and bandwidths of up to 48 Gbps. The use of fiber optic cable keeps the diameter of this active cable very low and gives it a very tight bending radius and low weight. It is ideal for use in homes, meeting rooms, and conference rooms as well as within buildings — and these are just a few of the possible uses. The simple Plug and Play installation is user-friendly; just plug it in and immediately enjoy optimal image quality. It supports numerous standards such as HDMI 2.1, HDCP 2.2 and HDR. Some of the many audio features supported are ARC, DTS-HD Master Audio and Dolby TrueHD. Cutting edge chip technology makes it possible to transfer the full HDMI® signal spectrum while also supporting uncompressed CED and EDID with very low latency.
| Features | |
| Cable length | 10 m |
| Connector 1 | HDMI Type A (Standard) |
| Connector 2 | HDMI Type A (Standard) |
| Connector 1 gender | Male |
| Connector 2 gender | Male |
| Connector 1 form factor | Straight |
| Connector 2 form factor | Straight |
| Product colour | Black |
| HDMI version | 2.1 |
| 3D | Yes |
| Supported graphics resolutions | 7680 x 4320 |
| Supported video modes | 1080p |
| Dolby technologies | DTS-HD Master Audio, Dolby TrueHD |
| Audio Return Channel (ARC) | Yes |
| HDMI Ethernet channel | Yes |
| HDCP | Yes |
| HDCP version | 2.2 |
| Data transfer rate | 48 Gbit/s |
| High Dynamic Range (HDR) supported | Yes |
| Supported digital audio channels (uncompressed) | 32 |
| Maximum refresh rate | 60 Hz |
| Connector contacts plating | Gold |
| Quantity per pack | 1 pc(s) |
| Operational conditions | |
| Operating temperature (T-T) | -10 - 80 øC |
| Operating relative humidity (H-H) | 0 - 85% |
| Weight & dimensions | |
| Cable diameter | 4.8 mm |
| Package volume | 2400000000 cmü |
| Package width | 200 mm |
| Package depth | 60 mm |
| Package height | 200 mm |
| Package weight | 390 g |
| Warranty | |
| Base Warranty | Non Non |
| Logistics data | |
| Harmonized System (HS) code | 84733080 |
