HDMI 2x2 Video Wall Processor Support 4K@60Hz (4:4:4)
ITCurry #: M9238180 | Article #: DS-43309-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Combine four interconnected Full HD displays (HDMI®) into a video wall – various display formations possible
- Combine up to 4 displays into a video wall of your choice
- Ideal for all kinds of visualizations for display windows, trade fairs or advertising
- Works with any HDMI® Full HD display
- Supports various display formations (horizontal, vertical or combined)
- Supports splitter mode (4 displays with the same content)
- Supports up to 4K / 60 Hz HDMI® input signal (YUV 4:4:4)
- Supports up to 4 x Full HD / 60 Hz (1920 x 1080p) output signals
- Total bandwidth of 18 Gbps for smooth playback in excellent quality
- On Screen Display (OSD) for mode and port display
- High-quality image scaling
With the DIGITUS® Video Wall Controller 2x2, you can transform a total of 4 TV sets or monitors with HDMI® into a large-format video wall. The controller enables you to distribute a high-resolution 4K signal across 4 Full HD displays to create a large image. You can be as creative as you like: set up a classic 2x2 monitor wall or arrange 2 to 4 monitors horizontally or vertically, combining them to make a video wall. By pressing a button on the device or the remote control included in delivery, you can switch between the different modes. The device also contains a splitter function that allows you to display the same image on all the monitors. With this professional tool, you are ideally equipped to display visualizations of all kinds for trade fairs, advertising or shop windows with a high degree of flexibility.
| Design | |
| Product colour | Black |
| Housing material | Metal |
| Features | |
| Supported video modes | 480i, 480p, 576i, 576p, 720p, 1080i, 1080p |
| Ports & interfaces | |
| HDMI input ports quantity | 1 |
| HDMI output ports quantity | 4 |
| Power | |
| Input voltage | 12 V |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 70 øC |
| Operating relative humidity (H-H) | 5 - 90% |
| Logistics data | |
| UK Trade Tariff code | 85176200 |
| Country of origin | China |
| Technical details | |
| Package volume | 2857.68 cmü |
| Weight & dimensions | |
| Width | 115 mm |
| Depth | 111 mm |
| Height | 27 mm |
| Weight | 395 g |
| Package width | 196 mm |
| Package depth | 243 mm |
| Package weight | 735 g |
| Packaging content | |
| Manual | Yes |
| Warranty | |
| Base Warranty | Non Non |
