Gigabit PoE Indoor Extender, 4-port, 85W 100m extension, cascadable, self powered
ITCurry #: M9239110 | Article #: DN-95128-1-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Extends the range of your PoE network by up to 100 m
- Supports 2/4 ports with PoE+, PoE
- Transfers data and power to your (PoE) network devices over one network cable
- No additional power supply needed
- Automatic detection of PoE network devices
- Easy installation thanks to Plug and Play
- Full bandwith over the entire PoE distance
The DIGITUS® Gigabit 4PPoE Extender supports the latest network technology to extend your Ethernet signal up to 100 meters. The amplifier is powered via 4PPoE (4-Pair Power over Ethernet or lower), so you don't need an additional power supply and you can use the device even where there are no power lines or sockets to significantly increase the range of the network. By supporting PoE+ and 4PPoE, devices with higher power consumption can also be connected, such as access points, POS systems or video telephones. Rely on advanced 4PPoE technology with the Gigabit 4PPoE Extender from DIGITUS®.
| Network | |
| Ethernet interface type | Gigabit Ethernet |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Power over Ethernet (PoE) | Yes |
| Networking standards | IEEE 802.3af, IEEE 802.3at |
| Duplex system | Full |
| Cable types supported | Cat5e |
| Features | |
| Product colour | Black |
| Easy to install | Yes |
| Maximum operating distance | 100 m |
| LED indicators | Link, PoE |
| Pin assignment & polarity | 1/2 (-), 3/6 (+), 7/8 (-), 4/5 (+) |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 5 |
| RJ-45 input ports | 1 |
| RJ-45 output ports | 4 |
| Power | |
| Power over Ethernet (PoE) voltage | 57 V |
| Output power | 60 W |
| Total Power over Ethernet (PoE) budget | 45 W |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 øC |
| Operating relative humidity (H-H) | 0 - 90% |
| Packaging content | |
| Number of products included | 1 pc(s) |
| Quick installation guide | Yes |
| Packaging data | |
| Package width | 127 mm |
| Package depth | 50 mm |
| Package height | 167 mm |
| Package weight | 442.778 g |
| Package volume | 1060.45 cmü |
| Logistics data | |
| UK Trade Tariff code | 85176200 |
| Country of origin | China |
| Warranty | |
| Base Warranty | Non Non |
