Vga Video Splitter Extender 4-port (89013)
ITCurry #: 18427671 | Article #: 89013-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Overview
The TruLink® 4-Port UXGA splitter/extender (also known as a VGA video splitter) is a robust hardware solution that can distribute any video signal to 4 different video outputs, while maintaining brilliant picture quality. Though powerful, this splitter is easy to use; just attach the cables, and you're ready to go! There is no software required, or complicated interface cards to install. This monitor splitter not only distributes, but also boosts your high resolution video signal up to 65 metres.
Includes power-saving mode, colour-coded connectors for the input and outputs, durable all-metal housing, power and activity LED indicators. Also applicable for VGA, SVGA, XGA, and MultiSync® resolution monitors. Cascade multiple units together for even more outputs.
Pack Contents:
- 4-port UXGA Monitor Splitter/Extender
- 100-240 VAC, 50-60 Hz, 12 VDC, 600 mA Universal power adapter (UK & EU)
- User manual
Connector 1
: (1) HD15 Female , (1) HD15 Male
| Ports & interfaces | |
| Video port type | VGA |
| Video out | 4x VGA |
| Video ports quantity | 4 |
| Connector(s) | HD15 Female, HD15 Male |
| DC-in jack | Yes |
| Features | |
| Product colour | Black |
| Full HD | No |
| Maximum operating distance | 65 m |
| Supported graphics resolutions | 1024 x 768 (XGA), 1600 x 1200 (UXGA), 640 x 480 (VGA), 800 x 600 (SVGA) |
| Power LED | Yes |
| Network | |
| Ethernet LAN | No |
| Power | |
| AC input voltage | 100-240 V |
| AC input frequency | 50 - 60 Hz |
| DC-in requirements | 12 V, 600 mA |
| Weight & dimensions | |
| Weight | 833 g |
| Packaging content | |
| Manual | Yes |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Warranty | |
| Base Warranty | Non Non |
