Switch Icx6430-24p Poe/24 Port 1g With 4x1g Sfp
ITCurry #: M1993914 | Article #: ICX6430-24P-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
- Offers enterprise-class stackable switching at an entry-level price, allowing organizations to buy what they need now and easily scale as demand grows and new technologies emerge
- Delivers unprecedented feature/price value for enterprise applications, including Unified Communications (UC) and mobility, with 10 Gigabit Ethernet (GbE) and PoE/PoE+
- Provides unmatched availability for low-cost switching with redundant uplink/stacking ports, hitless stacking failover, and configurable power redundancy
- Simplifies network operations and protects investments with Brocade HyperEdgeTM technology, enabling single-point network lifecycle management and advanced services sharing across a heterogeneous stack
- Includes the Brocade Assurance® Limited Lifetime Warranty and three years of technical support
Today’s organizations expect their enterprise campus LANs to deliver more services to more users at a lower cost. These services include next-generation business applications as well as anytime, anywhere access for mobile devices. At the same time, campus LANs must be able to scale easily to meet future demands and efficiently evolve within dynamic business environments.
Brocade® ICXTM 6430 and 6450 Switches provide enterprise-class stackable LAN switching solutions to meet the growing demands of campus networks. Designed for small to medium-size enterprises, branch offices, and distributed campuses, these intelligent, scalable edge switches deliver enterprise-class functionality at an affordable price—without compromising on performance and reliability. The Brocade ICX 6430 and 6450 are available in 24- and 48-port 10/100/1000 Mbps models and 1 Gigabit Ethernet (GbE) or 10 GbE dual-purpose uplink/stacking ports (see Figure 1)—with or without IEEE 802.3af Power over Ethernet (PoE) and 802.3at Power over Ethernet Plus (PoE+)—to support enterprise edge networking, wireless mobility, and IP communications.
| Management features | |
| Switch type | Managed |
| Switch layer | L2 |
| Quality of Service (QoS) support | Y |
| Web-based management | Y |
| System event log | Y |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| SFP/SFP+ slots quantity | 4 |
| SFP module slots quantity | 4 |
| Console port | RJ-45 |
| Power connector | DC-in jack |
| Network | |
| Networking standards | IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.1x, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3af, IEEE 802.3at, IEEE 802.3u, IEEE 802.3x, IEEE 802.3z |
| Port mirroring | Y |
| Full duplex | Y |
| IP routing | Y |
| Flow control support | Y |
| Link aggregation | Y |
| Broadcast storm control | Y |
| Rate limiting | Y |
| Auto MDI/MDI-X | Y |
| Spanning tree protocol | Y |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Number of VLANs | 4096 |
| Data transmission | |
| Supported data transfer rates | 10/100/1000 Mbps |
| Switching capacity | 56 Gbit/s |
| MAC address table | 8000 entries |
| Maximum data transfer rate | 1 Gbit/s |
| Jumbo frames support | Y |
| Security | |
| DHCP features | DHCP server, DHCP client |
| Access Control List (ACL) | Y |
| IGMP snooping | Y |
| MAC address filtering | Y |
| SSH/SSL support | Y |
| Warranty | |
| Base Warranty | Non Non |
| Multicast features | |
| Multicast support | Y |
| Design | |
| Rack mounting | Y |
| Stackable | Y |
| Form factor | 1U |
| Product colour | Black |
| LED indicators | Y |
| Safety | EN 55022: 2006+A1: 2007 Class A, EN 61000-3-2: 2006+A1:2009+A2:2009 Class A, EN 61000-3-3: 2008, EN 61000-6-1: 2007, EN 61000-6-3: 2007, EN 55024: 1998+A1:2001+A2:2003, EN 300 386 (V1.4.1): 2008, IEC 61000-4-2: 2008 ED. 2.0, IEC 61000-4-3: 2006+A1:2007+A2:2010 ED. 3.2, IEC 61000-4-4: 2004+A1:2010 ED. 2.0, IEC 61000-4-5: 2005 ED. 2.0, IEC 61000-4-6: 2008 ED. 3.0, IEC 61000-4-8: 2009 ED. 2.0, IEC 61000-4-11: 2004 ED. 2.0 |
| Performance | |
| Noise level | 39.2 dB |
| Mean time between failures (MTBF) | 505469 h |
| Power | |
| Power source | AC |
| Number of power supply units | 1 |
| Input voltage | 100 - 240 V |
| Power consumption (typical) | 525 W |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | N |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 45 øC |
| Storage temperature (T-T) | -40 - 70 øC |
| Storage relative humidity (H-H) | 5 - 95% |
| Non-operating altitude | 0 - 3000 m |
| Weight & dimensions | |
| Weight | 3.44 kg |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Other features | |
| Dimensions (WxDxH) | 443 x 240 x 43.4 mm |
| Connectivity technology | Wired |
| Networking features | Gigabit Ethernet |
| Wi-Fi | N |
| Power LED | Y |
| Input frequency | 50 - 60 Hz |
| Ethernet LAN | Y |
| Ethernet interface type | Gigabit Ethernet |
