AXIS Q9216-SLV is a compact and robust ligature-resistant (anti-ligature) corner-mount camera specially designed to provide a wide field-of-view and ensure no area is left uncovered. Available in white and elegant stainless-steel, this low power consuming camera is ideal for high-security installations such as in prisons and psychiatric wards.
See it all - day and night
AXIS Q9216-SLV offers 4 MP video quality and can cover 125 degrees horizontally and 95 degrees vertically, with no blind spots. Ideal in prison cells, it features 940 nm invisible IR illumination for unobtrusive surveillance in total darkness that won’t irritate or provoke the occupant. Wide Dynamic Range (WDR) ensures clarity even when there’s both dark and light areas in the scene. And, Axis Zipstream technology with support for both H.264 and H.265 video compression significantly reduces bandwidth and storage requirements without compromising image quality.
Occupant safety and privacy
With a ligature-resistant (anti-ligature) design, this robust camera can help prevent self-harm, especially important in high-security installations. The vandal-resistant IK10+ rated casing also offers IP66-rating for protection from dust and water. For added peace of mind, it includes a tampering alarm as well as shock and casing open detection so you can be informed if there’s any attempt to interfere with the camera. It features a removable built-in microphone which can be mounted if audio surveillance is required. Furthermore, AXIS Q9216-SLV includes an indication LED to see if the camera is active or not as well as polygonal privacy masking ensuring occupant privacy is respected.
Enhanced security features
This high-performance camera is packed with advanced security functionality to prevent unauthorized access and safeguard your system. Signed firmware ensures that only authorized firmware is installed and guarantees that it hasn't been compromised. Furthermore, it includes a Trusted Platform Module (TPM, FIPS 140-2 level 2 certified) to ensure secure storage of all cryptographic keys and certificates even in the event of a security breach.
Compact and easy to install
This compact camera offers simple and cost-effective installation. The chassis and mounting bracket are specially designed for versatile cable management and mounting options. It’s possible to connect to various conduits and connectivity devices to the back of the camera, such as AXIS T8643 PoE+ over Coax Compact or other compatible media converters and PoE extenders. Additionally, you can mount a conduit top box with space for additional conduits. Once the camera is mounted you can create a ligature-resistant (anti-ligature) installation by applying tamper-resistant security sealant along the edges to permanently seal it to the wall or ceiling. And, even if the back chassis is sealed to the wall, the camera can still be easily removed for service and maintenance.
Easy to clean and maintain
For ease of maintenance, the stainless-steel casing is IP66- and IP6k9k-rated to allow cleaning with high pressure, high temperature water jets. If the camera is severely soiled or defaced, the abrasion-resistant two-part front cover is easily removed, and the window can be cleaned more thoroughly with detergent or simple graffiti remover.
| Performance | |
| Type | IP security camera |
| Placement supported | Outdoor |
| Connectivity technology | Wired |
| PTZ control | Y |
| Wide Dynamic Range (WDR) | Y |
| Day/night mode | Y |
| Infrared (IR) cut-off filter | Y |
| Certification | EN 50130-4, EN 55032 A, EN 55035, IEC/EN 61000-6-1, IEC/EN 61000-6-2, FCC 15 B A, ICES-3(A)/NMB-3(A), VCCI A, KC KN-32 A, KC KN-35, RCM AS/NZS CISPR 32 A, CISPR 24, CISPR 35 IEC/EN/UL 62368-1, CAN/CSA C22.2 No. 62368-1, IEC/EN 62471 EN 50130-5 I, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78, IEC/EN 60529 IP66, EN 60529 IP69, ISO 20653 IP6K9K, IEC/EN 62262 IK10+, NEMA 250 4X NIST SP500-267 |
| Design | |
| Form factor | Dome |
| Mounting type | Ceiling/wall |
| Product colour | Stainless steel |
| Housing material | Stainless steel |
| International Protection (IP) code | IP66, IP69, IP69K |
| IK code | IK10+ |
| Camera | |
| Camera pan control | N |
| Camera tilt control | N |
| Lens viewing angle, horizontal | 125ø |
| Lens viewing angle, vertical | 95ø |
| Camera shutter speed | 1/32500 - 1/5 s |
| Image sensor | |
| Number of sensors | 1 |
| Optical sensor size | 25.4 / 2.5 mm (1 / 2.5") |
| Progressive scan | Y |
| Sensor type | CMOS |
| Lens system | |
| Number of lenses | 1 |
| Fixed focus | Y |
| Maximum aperture number | 2 |
| Fixed focal length | 2.4 mm |
| Night vision | |
| Night vision | Y |
| Night vision distance | 15 m |
| LED type | IR |
| Infra-red wavelength | 940 nm |
| Video | |
| Maximum resolution | 2304 x 1728 pixels |
| Video compression formats | AVC, H.264, H.265, HEVC, M-JPEG |
| Supported graphics resolutions | 320 x 240, 2304 x 1728 |
| Frame rate | 30 fps |
| Video streaming | Y |
| Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
| Text caption overlay | Y |
| Bit rate control | Variable Bit Rate (VBR) |
| Audio | |
| Audio system | 2-way |
| Audio system full duplex | Y |
| Sample rate | 48 kHz |
| Built-in microphone | Y |
| Voice codecs | G.711, G.726, OPUS |
| Network | |
| Ethernet LAN | Y |
| Ethernet interface type | Fast Ethernet |
| Networking standards | IEEE 802.1x, IEEE 802.3af, IEEE 802.3at |
| Supported network protocols | IPv4,IPv6 USGv6, HTTP, HTTPS , SSL/TLS , QoS L3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP , SNMP v1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, SFTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, LLDP, SIP |
| Wi-Fi | N |
| Bluetooth | N |
| Storage | |
| Built-in HDD | N |
| Card reader integrated | Y |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Flash memory | 512 MB |
| Internal memory | 1024 MB |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| Microphone in | Y |
| HDMI ports quantity | 1 |
| Terminal block port | Y |
| Security | |
| Password protection | Y |
| Video motion detection | Y |
| IP address filtering | Y |
| Security algorithms | EAP-TLS, FIPS 140-2 |
| HTTPS encryption | Y |
| Power | |
| Power source type | PoE |
| Power consumption (typical) | 4.7 W |
| Power consumption (max) | 10.8 W |
| Weight & dimensions | |
| Width | 209 mm |
| Depth | 176 mm |
| Height | 131 mm |
| Weight | 1.6 kg |
| Packaging content | |
| Number of cameras | 1 |
| Logistics data | |
| Harmonized System (HS) code | 85258900 |
| Warranty | |
| Base Warranty | Non Non |
