P9106-v Brushed Steel Network Camera
ITCurry #: 13835383 | Article #: 01553-001
slide 2 of 4
Price:
578.47
Ex VAT
Shipping:
FREE Shipping.
Out of Stock. Contact Us!
Related products
slide 6 to 10 of 15
Product Information
AXIS P9106-V Network Camera provides out-of-the-box optimized corner-to-corner coverage in 3 MP without any blind spots. It is enclosed in a vandal-resistant (IK10) and dust- and waterproof (IP66) casing. The abrasion- and chemical-resistant front window is easy to clean or replace, for efficient maintenance. AXIS P9106-V Network Camera is available in two variants: a brushed steel model with no visible screws which blends in with elegant spaces, such as elevators and commercial interiors, and a white model designed to be anti-ligature and anti-grip, ideal for classrooms, waiting rooms, and observation rooms in mental healthcare or custody cells.
| Performance | |
| Type | IP security camera |
| Placement supported | Indoor |
| Connectivity technology | Wired |
| PTZ control | Yes |
| PTZ modes | Digital PTZ |
| Wide Dynamic Range (WDR) | Yes |
| Number of languages | 12 |
| Languages support | Simplified Chinese, Traditional Chinese, German, English, Spanish, French, Italian, Japanese, Korean, Polish, Portuguese, Russian |
| Certification | EN 55032 Class A, EN 55024, FCC Part 15 Subpart B Class A, ICES-003 Class A, VCCI Class A, RCM AS/NZS CISPR 32 Class A, KC KN32 Class B, KC KN35, IEC/EN/UL 60950-1, IEC/EN 60529 IP66, IEC/EN 62262 Class IK10, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78 IEC 60721-3-5 5M3, NIST SP500-267 |
| Design | |
| Mounting type | Ceiling/wall |
| Product colour | Brushed steel |
| Housing material | Aluminium, Stainless steel, Zinc |
| Protection features | Dust resistant, Waterproof |
| International Protection (IP) code | IP66 |
| IK code | IK10 |
| Camera | |
| Minimum illumination | 0.35 lx |
| Tilt angle range | -5 - 5ø |
| Camera shutter speed | 1/32500 - 1/5 s |
| Image sensor | |
| Number of sensors | 1 |
| Optical sensor size | 25.4 / 3 mm (1 / 3") |
| Progressive scan | Yes |
| Sensor type | CMOS |
| Lens system | |
| Number of lenses | 1 |
| Fixed focus | Yes |
| Maximum aperture number | 2.4 |
| Fixed focal length | 1.8 mm |
| Video | |
| Maximum resolution | 2016 x 1512 pixels |
| Total megapixels | 3 MP |
| Video compression formats | AVC, H.264, M-JPEG, MPEG4 |
| Supported graphics resolutions | 320 x 240, 640 x 360, 1920 x 1080 (HD 1080) |
| Frame rate | 30 fps |
| Video streaming | Yes |
| Image quality adjustment | Brightness, Contrast, Saturation, Sharpness |
| Privacy masking | Yes |
| Text caption overlay | Yes |
| Bit rate control | Variable Bit Rate (VBR) |
| Network | |
| Ethernet LAN | Yes |
| Ethernet interface type | Fast Ethernet |
| Networking standards | IEEE 802.3af, IEEE 802.3at |
| Supported network protocols | IPv4, IPv6 USGv6, HTTP, HTTPS , SSL/TLS , QoS Layer 3 DiffServ, FTP, SFTP, CIFS/SMB, SMTP, Bonjour, UPnP , SNMP v1/v2c/v3 (MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS, SSH, LLDP |
| Cabling technology | 10/100Base-T(X) |
| Quality of Service (QoS) support | Yes |
| Streaming method | Multicast |
| Storage | |
| Card reader integrated | Yes |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC, MicroSDXC |
| Flash memory | 256 MB |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| Security | |
| Video motion detection | Yes |
| Active tampering alarm | Yes |
| Alert notification type | |
| Power | |
| Power source type | PoE |
| Power consumption (max) | 3.2 W |
| Power consumption (Power over Ethernet (PoE)) | 2.8 W |
| Operational conditions | |
| Operating temperature (T-T) | -15 - 55 øC |
| Storage temperature (T-T) | -40 - 65 øC |
| Operating relative humidity (H-H) | 15 - 85% |
| Weight & dimensions | |
| Width | 148 mm |
| Depth | 125 mm |
| Height | 93 mm |
| Weight | 790 g |
| Packaging content | |
| Number of cameras | 1 |
| Screws included | Yes |
| Quick installation guide | Yes |
| Logistics data | |
| Harmonized System (HS) code | 85258900 |
| Warranty | |
| Base Warranty | Non Non |
