16-outlet 0u Pdu With Current & VoltageLCD Display Overcurrent And Surge Protection (10a) (16x C13)
ITCurry #: 90314274 | Article #: PE1116SG-AT-G-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Engineered to enhance the efficiency of power distribution and power status monitoring in an IT environment, the ATEN Basic Metered PDU Series contains 0U members with 16 outlets and is available in IEC or NEMA socket configurations. The compact form factor plus the support for rack mount installation helps to save space and eliminates clutter. Benefits from the built-in surge protection module, the IT devices connected to the PDU are well-protected from sudden surges in electricity. The equipment downtime is reduced as a result of the overcurrent protection design.
To monitor the power status of the connected devices, the units feature dual 3-digit 7-segment displays to show the input voltage and output current in real-time. The Basic Metered PDUs provide secure, centralized power usage of data center IT equipment, including servers, storage systems, KVM switches, network devices, to optimize power consumption and asset management.
| Design | |
| PDU types | Basic, Metered |
| Rack capacity | 0U |
| Product colour | Black |
| Display | LCD |
| Ports & interfaces | |
| AC outlets quantity | 16 AC outlet(s) |
| Power plug | C14 coupler |
| AC outlet types | C13 coupler |
| Ethernet LAN (RJ-45) ports | 1 |
| Features | |
| Surge protection | Yes |
| Cable length | 3 m |
| Management features | |
| Monitoring | Current |
| Power | |
| Nominal input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Maximum current | 10 A |
| Load capacity | 2400 VA |
| Power protection features | Over current |
| Weight & dimensions | |
| Width | 44.4 mm |
| Depth | 967.1 mm |
| Height | 60 mm |
| Weight | 1.3 kg |
| Packaging content | |
| Cables included | AC |
| Manual | Yes |
| Rack mount kit | Yes |
| Packaging content | 1x Basic Metered 0U PDU with Surge Protection 1x Power Cord 1x L-Shaped Mounting Kit 1x User Instructions |
| Warranty | |
| Base Warranty | Non Non |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 øC |
| Storage temperature (T-T) | -20 - 60 øC |
| Operating altitude | 0 - 3000 m |
| Technical details | |
| Sustainability compliance | Yes |
| Compliance certificates | CE, Low Voltage Directive (LVD) |
| Logistics data | |
| Country of origin | China |
