Output |
Output Power Capacity |
1200 Watts / 1500 VA |
Nominal Output Voltage |
230V |
Output Frequency (sync to
mains) |
47 - 63 Hz |
Waveform Type |
Sine wave |
Output Connections |
8 x IEC 320 C13
2 x IEC Jumpers |
Input |
Nominal Input Voltage |
230 V |
Input Frequency |
50/60 Hz +/- 3 Hz (auto
sensing) |
Input Connections |
IEC-320 C14 |
Input voltage range for main
operations |
160 - 285 V |
Input Breaker Capacity |
20.0 A |
Cord Length |
1.83 meters |
Batteries &
Runtime |
Battery Type |
Maintenance-free sealed
Lead-Acid battery with suspended electrolyte : leakproof |
Typical recharge time |
3 hour(s) |
Replacement Battery |
APCRBC115 |
Communications &
Management |
Interface Port(s) |
SmartSlot
USB |
Pre-Installed SmartSlot Cards |
AP9631 |
Control panel |
Multi-function LCD status and
control console |
Audible Alarm |
Alarm when on battery :
distinctive low battery alarm : overload continuous tone alarm |
Emergency Power Off (EPO) |
Yes |
Surge Protection
and Filtering |
Surge energy rating |
645 Joules |
Filtering |
Full time multi-pole noise
filtering : 5% IEEE surge let-through : zero clamping response time :
meets UL 1449 |
Physical |
Height |
89.00 mm |
Width |
432.00 mm |
Depth |
490.00 mm |
Weight |
24.82 KG |
Rack Height |
2U |
Color |
Black |
Environmental |
Operating Environment |
0 - 45 øC |
Operating Relative Humidity
|
0 - 95% |
Operating Elevation |
0-3000 meters |
Storage Temperature |
-15 - 45 øC |
Storage Relative Humidity |
0 - 95% |
Storage Elevation |
0-15000 meters |
Audible noise at 1 meter from
surface of unit |
40.00 dBA |
Online Thermal Dissipation
|
133.00 BTU/hr |
Conformance |
Regulatory Approvals |
C-tick,CE,EN 50091-1,EN
50091-2,VDE |
Environmental Compliance |
RoHS 7b Exemption,REACH:
Contains No SVHCs
|
