Easy UPS SRV RM 6000VA 230V with RailKit, External Battery Pack
ITCurry #: 0280J063 | Article #: SRV6KRILRK
slide 2 of 6
Related products
slide 7 to 11 of 14
Product Information
High quality, Double-conversion On-line UPS designed for essential power protection needs even in the most unstable power conditions.
| Features | |
| UPS topology | Double-conversion (Online) |
| Output power capacity | 6 kVA |
| Output power | 6000 W |
| Waveform | Pure sine |
| Input operation voltage (min) | 110 V |
| Input operation voltage (max) | 300 V |
| Input frequency | 40/70 Hz |
| Output operation voltage (min) | 220 V |
| Output operation voltage (max) | 240 V |
| Output frequency | 50/60 Hz |
| Surge energy rating | 600 J |
| Efficiency | 94% |
| Crest factor | 3:1 |
| Output voltage Total Harmonic Distortion (THD) | 1% |
| Noise level | 55 dB |
| Surge protection | Yes |
| Audible alarm(s) | Yes |
| Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
| Auto shut-off | Yes |
| Power source type | AC |
| Detachable power cord | Yes |
| Ports & interfaces | |
| USB port | Yes |
| Battery | |
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery voltage | 240 V |
| Battery life (max) | 5 year(s) |
| Battery recharge time | 9 h |
| Hot-swap battery | Yes |
| Design | |
| Form factor | Rackmount |
| Rack capacity | 5U |
| Product colour | Black |
| Display type | LCD |
| International Protection (IP) code | IP20 |
| Certification | CE, UKCA, EAC, TISI |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 øC |
| Storage temperature (T-T) | -15 - 60 øC |
| Operating relative humidity (H-H) | 0 - 95% |
| Storage relative humidity (H-H) | 0 - 95% |
| Operating altitude | 0 - 3000 m |
| Non-operating altitude | 0 - 15000 m |
| Weight & dimensions | |
| Width | 438 mm |
| Depth | 615 mm |
| Height | 220 mm |
| Weight | 78 kg |
| Packaging data | |
| Rack mount kit | Yes |
| Cables included | RS-232, USB cable |
| Manual | Yes |
| Logistics data | |
| Harmonized System (HS) code | 85078000 |
| Warranty | |
| Base Warranty | Non Non |
Easy UPS SRV RM 6000VA 230V with RailKit, External Battery Pack
2616.66
