Easy UPS On-Line SRV RM Extended Runtime 6000VA 230V No Battery
ITCurry #: 0280J050 | Article #: SRVPM6KRIL-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
APC Easy UPS On-Line SRV RM Extended Runtime 6000VA 230V No Battery
High quality, Double-conversion On-line UPS designed for essential power protection needs even in the most unstable power conditionsHigh quality, Double-conversion On-line UPS designed for essential power protection needs even in the most unstable power conditions.
Includes: CD with software, USB cable, User Manual.
Automatic internal bypass: Supplies utility power to the connected loads in the event of a UPS power overload or fault.
Automatic restart of loads after UPS shutdown: Automatically starts up the connected equipment upon the return of utility power.
ECO Mode: Operating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection
EPO: Attach the device to an Emergency Power Off (EPO) system so that power can be turned off in an emergency situation.
Input power factor correction: Minimizes installation costs by enabling the use of smaller generators and cabling.
Intelligent battery management: Maximizes battery performance, life, and reliability through intelligent, precision charging.
LCD graphics display: Text and mimic diagrams that display modes of operation, system parameters and alarms.
Serial connectivity: Provides management of the UPS via a serial port.
USB connectivity: Provides management of the UPS via a USB port (not available on all models).
Features | |
UPS topology | Double-conversion (Online) |
Output power capacity | 6 kVA |
Output power | 6000 W |
Waveform | Pure sine |
Input frequency | 40/70 Hz |
Output operation voltage (min) | 220 V |
Output operation voltage (max) | 240 V |
Surge energy rating | 600 J |
Crest factor | 3:1 |
ECO mode | Yes |
Emergency Power Off (EPO) | Yes |
Audible alarm(s) | Yes |
Audible alarm modes | Alarm when on battery, Low battery alarm, Overload alarm |
Auto-restart | Yes |
Maintenance-free | Yes |
Ports & interfaces | |
Power plug | Terminal |
USB port | Yes |
USB 2.0 ports quantity | 1 |
USB port type | USB Type-B |
Serial interface | Yes |
Serial ports quantity | 1 |
Emergency Power Off (EPO) connector | Yes |
SmartSlot | Yes |
Battery | |
Battery technology | Sealed Lead Acid (VRLA) |
Battery recharge time | 3 h |
Automatic battery test | Yes |
Design | |
Form factor | Rackmount |
Rack capacity | 2U |
Product colour | Black |
Display type | LCD |
LED indicators | Yes |
Certification | CE, IEC 62040-1-1, IEC 62040-1-2 REACH |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 øC |
Operating relative humidity (H-H) | 0 - 95% |
Storage relative humidity (H-H) | 0 - 95% |
Operating altitude | 0 - 3000 m |
Non-operating altitude | 0 - 14763.6 m |
Technical details | |
Sustainability certificates | RoHS |
Compliance certificates | RoHS |
Weight & dimensions | |
Width | 438 mm |
Depth | 615 mm |
Height | 87 mm |
Weight | 14 kg |
Package width | 600 mm |
Package depth | 760 mm |
Package height | 240 mm |
Package weight | 18 kg |
Packaging data | |
Cables included | USB cable |
Manual | Yes |
Software CD | Yes |
Logistics data | |
Harmonized System (HS) code | 85078000 |
Other features | |
Nominal output voltage | 230 V |
Nominal input voltage | 230 V |
Warranty | |
Base Warranty | Non Non |
