Easy Rack 600mm/24U/1000mm with Roof Side Panel Castors Feet 4 Brackets No Bottom Black
ITCurry #: 0280J569 | Article #: ER6402-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Easy Rack ER6402 is EIA-310 standard pre-assembled IT enclosure with essential features for fast and easy deployment in low to medium density edge computing applications. ER6402 is perfect for remote server and converged applications with its 24U height to easily fit underneath counter tops or even into corner of a small rooms. This rack is developed in compact 600mm width & standard 1000mm deep to minimize floor space. This rack comes with Roof, keys, levelling feet, casters, side panels, mounting hardware, PDU mounting brackets and without bottom. With UL 2146 certification, this enclosure features integrated electrical grounding, ensuring the roof, front and rear doors are grounded to the frame. This rack cabinet ships fully assembled for faster installation or choose to ship unassembled for storage or transit in tight spaces and prefer to assemble onsite. ER6402 has quick release doors with spring pin design so that front doors are easily removed and can be moved to the opposite side or interchanged with rear doors. Solid roof of this rack prevents items from falling inside. Roof & rear door allow some cabling to pass through with tie-off points on frame for secured cable management. Easy Racks are easy to choose, install and accessorize with cooling, cable management & PDUs, including recently launched feature-rich, Easy Rack PDU series.
| Features | |
| Rack capacity | 24U |
| Type | Freestanding rack |
| Maximum weight capacity | 1199.75 kg |
| Maximum weight capacity (rolling) | 599.65 kg |
| Product colour | Black |
| Front door construction | Double perforated |
| Side panels included | Yes |
| Key lock | Yes |
| Back door key lock | Yes |
| Front door key lock | Yes |
| Side panel key lock | Yes |
| Adjustable feet | Yes |
| Castor wheels | Yes |
| Preassembled | Yes |
| Weight & dimensions | |
| Size (imperial) | 48.3 cm (19") |
| Width | 600 mm |
| Depth | 1000 mm |
| Height | 1198 mm |
| Weight | 71.4 kg |
| Mounting depth (min) | 19.1 cm |
| Mounting depth (max) | 83.8 cm |
| Packaging data | |
| Package width | 1050 mm |
| Package depth | 650 mm |
| Package height | 1330 mm |
| Package weight | 77 kg |
| Technical details | |
| Total carbon footprint (kg of CO2e) | 233.64 |
| Logistics data | |
| Harmonized System (HS) code | 85381000 |
| Warranty | |
| Base Warranty | Non Non |
