Bundle / DIN Rail - Panel Mount UPS with Standard Battery 500VA 325 Watts 230V + Replacement Battery

ITCurry #: 0280D906 | Article #: SUA500PDRI-S?KIT
Notify
Search More : UPS
Price:
556.23 Ex VAT
Shipping:
FREE Shipping.
Out of Stock. Contact Us!
Email us for assistance

Related products

slide 7 to 11 of 14

Product Information

The user-replaceable batteries increase availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR). It ensures clean,uninterrupted power to the loads when adding extra runtime to the UPS.

Specifications
General
Device Type UPS - DIN rail mountable
Colour Black
Power Device
UPS Technology Line interactive
Input Voltage AC 220/230/240 V
Input Voltage Range AC 160 - 285 V
Input Voltage Range (Adjustable) AC 151 - 302 V
Frequency Required 50/60 Hz
Input Connector(s) 1
Power Output Connectors Details 1 x hardwire 3-wire (1PH + N + G)
Output Voltage AC 220/230/240 V ± 5%
Power Capacity 325 Watt / 500 VA
Surge Suppression Yes
Surge Energy Rating 540 Joules
Circuit Protection Circuit breaker
Efficiency 94%
Battery
Quantity 1
Technology Lead Acid
Run Time (Up To) 8 min at full load
24 min at half load
Recharge Time 2.5 hours
Networking
Remote Management Interface RS-232
Expansion / Connectivity
Interfaces 1 x management (RS-232) - 9 pin D-Sub (DB-9)
Expansion Slot(s) 1 (total) / 1 (free) x SmartSlot
Miscellaneous
Compliant Standards UL,UL 1449,RoHS,REACH
Environmental Parameters
Min Operating Temperature 0 °C
Max Operating Temperature 40 °C
Humidity Range Operating 0 - 95%
Sound Emission 55 dBA
Dimensions & Weight
Width 36.2 cm
Depth 17.1 cm
Height 14.8 cm
Weight 12.86 kg
Base Warranty Non Non
