Product Information
Battery failure notification
Provides early-warning fault analysis on batteries enabling timely preventive maintenance
Resettable circuit breaker
Easy recovery from overloads; no need to replace a fuse.
Cold-start capable
Provides temporary battery power when the utility power is out.
Disconnected battery notification
Warns when a battery is not available to provide backup power.
Audible alarms
Provides notification of changing utility power and UPS power conditions
Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.
Automatic Voltage Regulation (AVR)
Automatically steps up low voltage and steps down high voltage to levels that are suitable for your equipment.
Features | |
Output power capacity | 0.65 kVA |
Output power | 390 W |
Input operation voltage (min) | 140 V |
Input operation voltage (max) | 300 V |
Input frequency | 45/65 Hz |
Output operation voltage (min) | 230 V |
Output operation voltage (max) | 230 V |
Maximum current | 7 A |
Surge energy rating | 273 J |
Efficiency | 97% |
Noise level | 45 dB |
Audible alarm(s) | Yes |
Ports & interfaces | |
AC outlet types | C13 coupler |
AC outlets quantity | 5 AC outlet(s) |
Number of output IEC jumpers | 1 |
Battery | |
Battery recharge time | 8 h |
Design | |
Cable length | 1.16 m |
Product colour | Black |
LED indicators | Status |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 øC |
Storage temperature (T-T) | -15 - 45 øC |
Operating relative humidity (H-H) | 0 - 95% |
Certificates | |
Compliance certificates | RoHS |
Certification | CE, EN/IEC 60950-1, GOST, NEMKO |
Weight & dimensions | |
Width | 115 mm |
Depth | 257 mm |
Height | 200 mm |
Weight | 6.2 kg |
Packaging data | |
Package width | 198 mm |
Package depth | 340 mm |
Package height | 270 mm |
Package weight | 7 kg |
Warranty | |
Base Warranty | Non Non |
