Desktop Monitor - Me2401 - 24in - 1920x1080 (full Hd)
ITCurry #: 92942507 | Article #: ME2401-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
24'' Clinical Review Monitor for Modern Medical Workstations
Introducing the ME-2401, a 24” clinical review monitor thoughtfully crafted to revolutionise document scrutiny in clinics. Every meticulous detail is accentuated, enhancing patient record evaluations. Beyond its crisp display, the monitor champions safety with its IEC/EN 60601 certified power adaptor. Its sophisticated ergonomic design, combined with VESA mounting compatibility, promises versatility – from a traditional desk setup to the hustle and bustle of medical trolleys.
Crisp Image Quality
Tailored for medical precision, the ME-2401 features 2MP (1920 x 1080) resolution, offering unmatched clarity, facilitating accurate diagnostics and integration.
Safety First
Our monitor features an IEC/EN60601 certified power adaptor, ensuring safe, consistent operations.
Flexible Ergonomics
Whether it’s tilt, pivot, or swivel, find your perfect angle. Optimise efficiency and maintain comfort even during those extended reviews.
Versatile Mounting
Adaptability at its finest. With a 100 x 100mm VESA specification, mount the ME-2401 with ease, be it on dynamic medical trolleys or sleek wall setups
Broad Connectivity
Integration has never been smoother. With HDMI and DisplayPort interfaces, ME-2401 caters to the diverse connectivity needs of modern medical systems.
Eye-Care Technology
Prioritising your well-being. Crafted for extended usage, our monitor minimises eye strain through its flicker-free performance and protective blue light filter.
| Display | |
| Display diagonal | 60.5 cm (23.8") |
| Display resolution | 1920 x 1080 pixels |
| HD type | Full HD |
| Native aspect ratio | 16:9 |
| Display technology | LED |
| Panel type | IPS |
| Touchscreen | No |
| Display brightness (typical) | 250 cd/mý |
| Response time | 5 ms |
| Anti-glare screen | Yes |
| Screen shape | Flat |
| Contrast ratio (typical) | 20000000:1 |
| Viewing angle, horizontal | 178ø |
| Viewing angle, vertical | 178ø |
| Display number of colours | 16.7 million colours |
| Pixel pitch | 0.275 x 0.275 mm |
| Digital horizontal frequency | 30 - 80 kHz |
| Digital vertical frequency | 56 - 75 Hz |
| Haze rate | 25% |
| Surface hardness | 3H |
| Multimedia | |
| Number of speakers | 2 |
| RMS rated power | 4 W |
| Built-in speaker(s) | Yes |
| Built-in camera | No |
| Design | |
| Market positioning | Medical |
| Product colour | White |
| Ports & interfaces | |
| Built-in USB hub | No |
| HDMI | Yes |
| HDMI ports quantity | 1 |
| HDMI version | 1.4 |
| DisplayPorts quantity | 1 |
| Audio output | Yes |
| Headphone out | Yes |
| Headphone outputs | 1 |
| Headphone connectivity | 3.5 mm |
| Ergonomics | |
| VESA mounting | Yes |
| Panel mounting interface | 100 x 100 mm |
| Wall mountable | Yes |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Height adjustment | Yes |
| Adjustable height (max) | 12 cm |
| Pivot | Yes |
| Pivot angle | 0 - 90ø |
| Swivelling | Yes |
| Swivel angle range | -45 - 45ø |
| Tilt adjustment | Yes |
| Tilt angle range | -5 - 20ø |
| Power | |
| Energy efficiency class (SDR) | E |
| Energy efficiency class (HDR) | Not available |
| Energy consumption (SDR) per 1000 hours | 18 kWh |
| Power consumption (typical) | 18 W |
| Power consumption (standby) | 0.5 W |
| Power consumption (off) | 0.3 W |
| AC adapter output voltage | 12 V |
| Power supply type | External |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 øC |
| Storage temperature (T-T) | -20 - 60 øC |
| Operating relative humidity (H-H) | 10 - 85% |
| Storage relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
| Width (with stand) | 540 mm |
| Depth (with stand) | 190 mm |
| Height (with stand) | 537.4 mm |
| Weight (with stand) | 5 kg |
| Width (without stand) | 540 mm |
| Depth (without stand) | 48.6 mm |
| Height (without stand) | 324.4 mm |
| Weight (without stand) | 3 kg |
| Packaging data | |
| Package width | 654 mm |
| Package depth | 182 mm |
| Package height | 407 mm |
| Package weight | 7.1 kg |
| Packaging content | |
| Stand included | Yes |
| Cables included | AC, HDMI |
| Power adapter included | Yes |
| Other features | |
| Compliance certificates | CE, EAC, Low Voltage Directive (LVD), REACH, RoHS, UKCA, WEEE |
| Warranty | |
| Base Warranty | Non Non |
