Informations sur le produit

Features
  • 95.5% efficiency in online mode and 98% in Eco mode for energy savings
  • Comprehensive safety features including overcharge and overload protection
  • Multiple management interfaces with SNMP 3 support for easy monitoring
  • 4 hour recharge time for minimal downtime
  • Up to 18 minutes of runtime at full load to ensure safe equipment shutdown
Specifications

General

Colour Black
Localisation EMEA
Height (Rack Units) 7U
Device Type UPS - Power Factor Correction (PFC) - rack-mountable / external

Expansion / Connectivity

Expansion Slots 1 (total) / 0 (free) x Intelligent Slot
Interfaces 1 x management (USB) 1 x management (RS-232) 1 x EPO (emergency power off) 1 x management (Ethernet) - RJ-45 1 x sensor - RS-485

Manufacturer Warranty

Service & Support Limited warranty - 3 years Limited warranty - batteries - 2 years

Networking

Remote Management Protocol SNMP 3
Remote Management Interface Ethernet, RS-232, USB

Miscellaneous

Rack Mounting Kit Included
Features Emergency power off, LCD display, overheat protection, internal bypass, Automatic Voltage Regulation (AVR), overcharge protection, overload protection, cold-start function, short-circuit protection, hot-swappable batteries, low voltage protection, overdischarge protection, double conversion
Compliant Standards UL, RoHS, REACH, EN 62040-1:2008+A1:2013, ISTA 2B, IEC 62040-1:2013, BS 62040-1-2013, IEC 62040-2-2016, EN 62040-2-2018, BS 62040-2-2018, Energy Star 2.0

Software / System Requirements

Software Included SmartZone Cloud, SmartZone mPower

Environmental Parameters

Min Operating Temperature 0 °C
Max Operating Temperature 40 °C
Sound Emission 58 dB
Humidity Range Operating 0 - 95% RH (non-condensing)

Battery

Quantity 40
Technology Lead Acid
Recharge Time 4 hour(s)
Transfer Time 0 ms
Features Maintenance free, valve-regulated
Voltage Provided DC 480 V
Run Time (Up To) 18 min at full load 36 min at half load

Power Device

Power Factor (PF) 1.0
Frequency Provided 50/60 Hz
Input Voltage AC 220/230/240 V
Output Waveform Sinewave
UPS Technology On-line
Dataline Surge Protection Network - RJ-45
Frequency Required 40 - 70 Hz
Input Wiring 3-phase
Output Voltage AC 220/230/240 V 50/60 Hz
Power Capacity 10000 Watt / 10000 VA
Input Connectors 1 x hardwire 5-wire (3PH + N + PE)
Input Voltage Range AC 138 - 485 V / 305 - 485 V
Power Output Connectors Details 1 x hardwire 5-wire (3PH + N + PE) 1 x hardwire 3-wire (1PH + N + PE)
Efficiency 98% Eco mode, 95.5% online mode

Dimensions & Weight

Height 17.5 cm
Width 44.3 cm
Depth 89.6 cm
Weight 156 kg

Sustainability Information

ENERGY STAR Yes
Base Warranty Non Non
