| Output |


		| Output Power Capacity  |
		980 Watts / 1500 VA  |


		| Max Configurable Power  |
		980 Watts / 1500 VA  |


		| Nominal Output Voltage  |
		230 V  |


		| Output Voltage Distortion  |
		Less than 5% at full load  |


		| Output Frequency (sync to
		mains)  |
		47 - 53 Hz for 50 Hz
		nominal,57 - 63 Hz for 60 Hz nominal  |


		| Waveform Type  |
		Sine wave  |


		| Output Connections |
		8 x IEC 320 C13
		2 x IEC Jumpers  |


		| Input |


		| Nominal Input Voltage  |
		230 V  |


		| Input Frequency  |
		50/60 Hz +/- 3 Hz (auto
		sensing)  |


		| Input Connections  |
		IEC-320 C14  |


		| Cord Length  |
		1.83 meters  |


		| Input voltage range for main
		operations  |
		160 - 286 V  |


		| Input voltage adjustable range
		for mains operation |
		151 - 302 V  |


		| Batteries &
		Runtime |


		| Battery Type |
		Maintenance-free sealed
		Lead-Acid battery with suspended electrolyte : leakproof  |


		| Typical recharge time  |
		3 hour(s)  |


		| Replacement Battery  |
		RBC7 |


		| Communications &
		Management |


		| Interface Port(s)  |
		SmartSlot
		USB  |


		| Available SmartSlot Interface
		 |
		1 |


		| Control panel  |
		Multi-function LCD status and
		control console  |


		| Audible Alarm  |
		Alarm when on battery :
		distinctive low battery alarm : overload continuous tone alarm  |


		| Surge Protection
		and Filtering |


		| Surge energy rating |
		459 Joules  |


		| Filtering  |
		Full time multi-pole noise
		filtering : 0.3% IEEE surge let-through : zero clamping response time :
		meets UL 1449  |


		| Physical |


		| Height  |
		219.00 mm  |


		| Width  |
		171.00 mm  |


		| Depth  |
		439.00 mm |


		| Weight  |
		24.09 kg |


		| Color  |
		Black  |


		| Environmental |


		| Operating Environment  |
		0 - 40 øC  |


		| Operating Relative Humidity
		 |
		0 - 95%  |


		| Operating Elevation  |
		0-3000 meters  |


		| Storage Temperature  |
		-15 - 45 øC  |


		| Storage Relative Humidity  |
		0 - 95%  |


		| Storage Elevation  |
		0-15000 meters  |


		| Audible noise at 1 meter from
		surface of unit  |
		45.00 dBA  |


		| Online Thermal Dissipation
		 |
		135.00 BTU/hr  |


		| Conformance |


		| Regulatory Approvals  |
		C-tick,CE,EN 50091-1,EN
		50091-2,VDE  |


		| Environmental Compliance  |
		RoHS 7b Exemption,REACH:
		Contains No SVHCs
		 |
