Product Information
The TC52/TC57 Touch Computers build on the highly successful TC51/TC56, adding a new platform and new capabilities to deliver the ultimate in enterprise-class touch computing. You get the ultimate user experience — the simplicity of Android with all the business features workers need to maximize productivity and minimize process cycle times. You get the ultimate technology advancements on a cutting edge platform, maximizing the benefits of mobility today, with the future proofing you need to serve your business tomorrow. You get the ultimate collection of value-add apps, Mobility DNA™, with four new complimentary solutions that deliver unparalleled functionality — including the best possible WiFi performance, centralized control of the device update process, control over access to Google Mobile Services (GMS) and more. And optional Visibility Services offer the ultimate in device management capabilities to maximize device value.
The ultimate user experience
Android for instant familiarity
Your workers already know how to use an Android device, virtually eliminating training time and adoption curves. And you can deliver the highly-graphic interactive apps today’s workers expect.
Advanced touchscreen technology
Give your workers touchscreen simplicity. The 5 in. display offers plenty of real estate for graphics-intensive intuitive applications.
The easy, familiar and flexible multi-touch operation works even when wet, with a gloved finger or a stylus. And with best-in-class outdoor readability, the screen is easy to read, even in bright sunlight.
Easily capture it all — barcodes, labels and documents
Advanced scanning technology and PRZM Intelligent Imaging deliver lightning fast capture of printed and electronic 1D and 2D barcodes, including Digimarc — regardless of condition. The expanded working range and wide field of view allow workers to scan barcodes nearer and farther away, while omnidirectional scanning delivers true point and shoot performance — no need to ever align the device with the barcode. Need to capture multiple barcodes on a single label or data on a form, such as checkboxes, text fields, signatures and more? You can do it all with the press of a single button with Zebra’s SimulScan, a no-cost pre-installed Mobility DNA application.
Full shift power your workers can count on
The PowerPrecision+ high capacity battery delivers an impressive 14 hours of power1 — plenty for the longest shift. With Warm Swap mode, swapping batteries is fast and easy — there’s no need to turn off the device or close active apps. And with fast charging, batteries are fully charged and ready to go in record time.
Active Edge™ Touch Zone for One-touch Feature Access
Your users can easily create unique dedicated soft keys on either side of the display to access their most frequently used device features and applications with single touch simplicity — from the scanner, camera and line-of-business applications to push-to-talk and text messaging.
| Display | |
| Display diagonal | 12.7 cm (5") |
| Display resolution | 1280 x 720 pixels |
| Touchscreen | Yes |
| Touch technology | Dual-touch |
| Touchscreen type | Capacitive |
| Display glass type | Gorilla Glass |
| Memory | |
| Internal memory | 4 GB |
| Flash memory | 32 GB |
| Compatible memory cards | MicroSD (TransFlash) |
| Maximum memory card size | 256 GB |
| Processor | |
| Processor model | 660 |
| Processor frequency | 2.45 GHz |
| Processor family | Snapdragon |
| Number of cores | 8 |
| Built-in processor | Yes |
| Network | |
| Wi-Fi | Yes |
| Wi-Fi standards | 802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac) |
| Bluetooth | Yes |
| SIM card type | NanoSIM + eSIM |
| Security algorithms | AES, EAP-TLS, EAP-TTLS, TKIP, WMM, WPA, WPA-Enterprise, WPA2, WPA2-Enterprise, WPA3, WPA3-Enterprise |
| Near Field Communication (NFC) | Yes |
| GPS Performance | |
| GPS (satellite) | Yes |
| Assisted GPS (A-GPS) | Yes |
| GLONASS | Yes |
| BeiDou | Yes |
| Galileo | Yes |
| Camera | |
| Built-in camera | Yes |
| Rear camera resolution (numeric) | 13 MP |
| Front camera | Yes |
| Front camera resolution (numeric) | 5 MP |
| Auto focus | Yes |
| Audio | |
| Built-in microphone | Yes |
| Ports & interfaces | |
| USB 2.0 ports quantity | 1 |
| Performance | |
| Product colour | Black, Silver |
| Barcode reader | Yes |
| Scanner type | 1D/2D |
| Phone function | Yes |
| Google Mobile Services (GMS) supported | Yes |
| Vibrating alert | Yes |
| Sensors | |
| Ambient light sensor | Yes |
| Accelerometer | Yes |
| Proximity sensor | Yes |
| Gyroscope | Yes |
| Magnetometer | Yes |
| Pressure sensor | Yes |
| Software | |
| Operating system installed | Android |
| Operating system version | 10 |
| Power | |
| Battery capacity | 4150 mAh |
| Fast charging | Yes |
| Weight & dimensions | |
| Weight | 249 g |
| Width | 18.6 mm |
| Depth | 75.5 mm |
| Height | 155 mm |
| Operational conditions | |
| Operating relative humidity (H-H) | 5 - 95% |
| Operating temperature (T-T) | -20 - 50 øC |
| Storage temperature (T-T) | -40 - 70 øC |
| Technical details | |
| Electrostatic Discharge (ESD) protection (air) | 15 kV |
| Electrostatic Discharge (ESD) protection (contact) | 8 kV |
| Logistics data | |
| Harmonized System (HS) code | 84713000 |
| Warranty | |
| Base Warranty | Non Non |
