Scanner Barcode Ds3678 Rugged Area Imager High Performence Cordless FIPS Green Vib
ITCurry #: 1825L050 | Article #: DS3678-HP2F003VKWW-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Revolutionize your operations with the Zebra DS3608-HP (corded) and DS3678-HP (cordless) ultra-rugged barcode scanners. Designed for demanding environments, these high-performance scanners capture 1D and 2D barcodes, OCR data, and images with exceptional speed and accuracy. Scan barcodes from up to 7 feet away, even on damaged or poorly printed labels.
The Zebra DS3600-HP barcode scanners rugged construction withstands harsh conditions, ensuring maximum uptime and reliability. Improve data capture efficiency, reduce errors, and enhance productivity with these versatile Zebra barcode readers. Experience lightning-fast barcode scanning, easy deployment, and superior manageability. Optimize your workflows with the Zebra DS3608-HP/DS3678-HP scanners.
| Scanning | |
| Type | Handheld bar code reader |
| Scanner type | 1D/2D |
| Sensor type | Laser |
| Linear (1D) barcodes supported | Codabar, Code 11, Code 128, Code 39, Code 93, GS1-128 (UCC/EAN-128), MSI, Plessey, U.P.C. |
| 2D (matrix & stacked) barcodes supported | Aztec Code, Composite Codes, Data Matrix, Han Xin, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, TLC-39 |
| Wavelength | 655 nm |
| Tilt reading angle | -65 - 65ø |
| Pitch reading angle | -65 - 65ø |
| Yaw reading angle | -45 - 45ø |
| Ports & interfaces | |
| Connectivity technology | Wired & Wireless |
| Standard interfaces | Keyboard wedge, RS-232, USB |
| Wireless range | 100 m |
| Bluetooth version | 4.0 |
| Bluetooth Low Energy (BLE) | Yes |
| Performance | |
| International Protection (IP) code | IP67 |
| Protection features | Dust resistant, Shock resistant, Water resistant |
| LED indicators | Yes |
| Product colour | Black, Green |
| Programming function | Yes |
| Power | |
| Power source type | Battery |
| Battery technology | Lithium-Ion (Li-Ion) |
| Battery capacity | 3100 mAh |
| Number of reads per charge | 100000 |
| Weight & dimensions | |
| Width | 142 mm |
| Depth | 76 mm |
| Height | 185 mm |
| Weight | 411 g |
| Operational conditions | |
| Operating temperature (T-T) | -20 - 50 øC |
| Storage temperature (T-T) | -40 - 70 øC |
| Operating relative humidity (H-H) | 5 - 95% |
| Warranty | |
| Base Warranty | Non Non |
