Product Information
Get economical power today with the NeoECO Classic, Antec's high-efficiency power supply solution. Featuring 80 PLUS® BRONZE certification, a quiet 120 mm DBB fan, All Japanese capacitors and Universal Input with Active Power Factor Correction, NeoECO Classic gives you a cooler, quieter system, all powered by Continuous Power.
Warranty | |
Base Warranty | Non Non |
Power | |
Total power | 650 W |
AC input voltage | 100 - 240 V |
AC input frequency | 47 - 63 Hz |
Input current | 5 - 10 A |
Power Factor Correction (PFC) type | Active |
Combined power (+3.3V) | 120 W |
Combined power (+12V) | 600 W |
Combined power (+5V) | 120 W |
Combined power (-12V) | 3.6 W |
Combined power (+5Vsb) | 12.5 W |
Max output current (+3.3V) | 20 A |
Max output current (+12V) | 50 A |
Max output current (+5V) | 17 A |
Max output current (-12V) | 0.3 A |
Max output current (+5Vsb) | 2.5 A |
Efficiency | 88% |
Ports & interfaces | |
Motherboard power connector | 20+4 pin ATX |
Number of SATA power connectors | 8 |
Peripheral (Molex) power connectors (4-pin) | 3 |
PCI Express power connectors (6+2 pin) | 2 |
CPU power connector (4+4 pin) | Yes |
Floppy drive power connector | 1 |
Cabling type | Non-Modular |
Performance | |
80 PLUS certification | 80 PLUS Bronze |
Purpose | PC |
Power supply unit (PSU) form factor | ATX |
Safety | cTUVus, FCC, TšV, CE, CB, EAC, RCM |
Design | |
Product colour | Black |
Cooling type | Active |
Fan diameter | 12 cm |
Number of fans | 1 fan(s) |
Fan location | Top |
Weight & dimensions | |
Width | 150 mm |
Depth | 140 mm |
Height | 86 mm |
Weight | 1.7 kg |
Technical details | |
Compliance certificates | RoHS |
Logistics data | |
Harmonized System (HS) code | 84733020 |
