220xi - Thermal Printer - 300 Dpi - 10/100 Ethernet For China Only
ITCurry #: 18258355 | Article #: 220-809-00003-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Built for high-volume applications and harsh environments, Zebra's Xi Series label printers deliver superior print quality and reliability. Boost productivity with faster print and connection speeds, and reduce downtime with early warning.
Used For:
- Asset Management
- Cross Docking
- Inventory Management
- Receiving/Shipping
- Work-in-Process Tracking
- Compliance Labeling
- Order Labeling
- Quality Control
220Xi4 Industrial Printer
Designed for fast printing of chemical drum and other wide-label applications, count on high-performance when you trust the rugged reliability of this thermal label printer.
Printing | |
Print technology | Thermal transfer |
Colour | No |
Maximum resolution | 203 x 203 DPI |
Maximum printing width | 21.6 cm |
Paper handling | |
Ribbon width | 17 cm |
Ribbon length | 450 m |
Maximum label width | 22.4 cm |
Maximum roll diameter | 20.3 cm |
Media thickness | 0.076 - 0.305 mm |
Media thickness (imperial) | 0.003 - 0.12" |
Core diameter | 7.6 cm |
Ports & interfaces | |
Connectivity technology | Wired |
Ethernet LAN | Yes |
Wi-Fi | No |
USB port | Yes |
USB 2.0 ports quantity | 1 |
Parallel ports quantity | 1 |
RS-232 ports | 1 |
RS-232 interface | Yes |
Standard interfaces | Ethernet |
Optional connectivity | Twinax, Wireless LAN |
Performance | |
Page description languages | XML, ZPL, ZPL II |
Internal memory | 16 MB |
Flash memory | 8 MB |
Built-in barcodes | 1D, 2D, CODABAR (NW-7), Code 128 (A/B/C), Code 39, Code 49, Code 93, EAN13, EAN8, Industrial 2/5, Interleaved 2/5, MaxiCode, PDF417, POSTNET, QR Code, UPC-A, UPC-E |
Built-in processor | 32-bit RISC |
Processor frequency | 133 MHz |
Certification | BSMI, cTUVus, CCC, CE, C-Tick, EN55022 B, EN55024, EN61000-3-2,3, FCC B, GOST-R, ICES-003 B, IEC 60950-1 / EN60950, KCC, NOM, S Mark, STB, UkrSEPRO, VCCI, ZIK |
Design | |
Product colour | Black, Grey |
Built-in display | Yes |
Display | LCD |
Display resolution | 240 x 128 pixels |
Power | |
Power requirements | 90 - 264 VAC, 48 - 62 Hz |
Operational conditions | |
Operating relative humidity (H-H) | 20 - 85% |
Storage relative humidity (H-H) | 5 - 85% |
Operating temperature (T-T) | 40 - 105 øF |
Operating temperature (T-T) | 5 - 40 øC |
Storage temperature (T-T) | -40 - 60 øC |
Storage temperature (T-T) | -40 - 140 øF |
Weight & dimensions | |
Width | 401.6 mm |
Depth | 517.5 mm |
Height | 393.7 mm |
Weight | 32.7 kg |
Packaging data | |
Package type | Box |
Packaging content | |
Cables included | AC |
Logistics data | |
Harmonized System (HS) code | 84433210 |
Technical details | |
Sustainability certificates | ENERGY STAR |
Other features | |
Network ready | Yes |
Warranty | |
Base Warranty | Non Non |
