140xi4 - Thermal Printer - 203dpi - Z-net / Rs232 / parallel / USB Rew.w. Peel
ITCurry #: 18254059 | Article #: 140-80E-00203-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Another addition to Zebra’s Xi4 product line is the 140Xi4. Built on the proven Xi series platform that is known for rugged durability and performance, the new Xi4 brings several additional features to high-volume, mission-critical applications and environments that require 24 x 7 operations. Building on these high-performance hallmarks, the Xi4 now provides several new features and benefits:
- Increased print speeds up to 14"/356 mm per second for increased batch and print/apply productivity.
- LCD content customizable to user needs.
- Large, easy to use, multilingual LCD screen.
- Flexible connectivity including simultaneous parallel/Ethernet with internal Ethernet included as standard in the product.
- Advanced ribbon- and media-low LCD/e-mail alerts.
- Intelligent printhead system.
Zebra's 140Xi4 for print widths up to 5” (128 mm) gets the job done fast, printing at up to 14" (356 mm) per second—one of the fastest technologies on the market. The 140Xi4 is also well-suited for applications in which labels are required quickly, on demand or in batches.
Benefits
-Faster Ethernet performance with Internal ZebraNet 10/100 PrintServer - included standard.
-Handles everything from paper to specialty label/tag stocks.
-Satisfies high-volume label requirements.
-Offers a wide range of connectivity solutions.
Standard Features
-Print methods: Thermal transfer or direct thermal.
-Construction: 12-gauge steel frame.
-Single 32 bit 133 Mhz RISC processor.
-16 MB SDRAM; 8 MB non-volatile Flash memory.
-Automatic media/ribbon sensing capability.
-Improved head test for element out.
-Auto calibration.
-Clear media side door for ease of supplies monitoring.
-300 unique darkness settings.
-RS-232, Parallel ports.
-USB 2.0 port.
-Internal ZebraNet 10/100 PrintServer.
-ZPL or ZPL II Programming Language.
-XML enabled printing.
-Mirror feature allows user-defined printer configurations to be retrieved from the network.
-Create and design customizable printer LCD menus.
-Large (240W x 128H pixels), multilingual, backlit LCD display.
-Transmissive and reflective media sensors.
-Multi-level Element Energy Equalizer (E3) for superior print quality.
-Unicode™ - Compliant.
-Intelligent printhead.
| Printing | |
| Print technology | Direct thermal / Thermal transfer |
| Colour | No |
| Maximum resolution | 203 x 203 DPI |
| Print speed | 356 mm/sec |
| Paper handling | |
| Autocutter | Yes |
| Ribbon length | 300 m |
| Maximum roll diameter | 20.3 cm |
| Media thickness | 0.076 - 0.305 mm |
| Media thickness (imperial) | 0.003 - 0.012" |
| Supported paper width | 128 mm |
| Supported paper width (imperial) | 5.04" |
| Maximum media length | 3.81 m |
| Maximum media length (imperial) | 150" |
| Core diameter | 7.6 cm |
| Ports & interfaces | |
| Connectivity technology | Wired |
| Parallel ports quantity | 1 |
| RS-232 ports | 1 |
| Standard interfaces | USB 2.0 |
| Performance | |
| Page description languages | XML, ZPL II |
| Internal memory | 16 MB |
| Flash memory | 8 MB |
| Built-in barcodes | Code 39, Code 49, Code 93, MaxiCode, PDF417, Postnet, QR Code, UPC-A, UPC-E |
| Certification | BSMI, cTUVus, CCC, CE, C-Tick, EN55022 B, EN55024, EN61000-3-2,3, FCC B, GOST-R, ICES-003 B, IEC 60950-1 / EN60950, KCC, NOM, S Mark, STB, UkrSEPRO, VCCI, ZIK |
| Power | |
| Power requirements | 90 - 264 VAC, 48 - 62 Hz |
| Operational conditions | |
| Operating relative humidity (H-H) | 20 - 85% |
| Storage relative humidity (H-H) | 5 - 85% |
| Operating temperature (T-T) | 0 - 40 øC |
| Storage temperature (T-T) | -40 - 60 øC |
| Weight & dimensions | |
| Weight | 25 kg |
| Logistics data | |
| Harmonized System (HS) code | 84433210 |
| Other features | |
| Dimensions (WxDxH) | 287.3 x 517.5 x 393.7 mm |
| Warranty | |
| Base Warranty | Non Non |
