Hard Drive - WD Red Plus WD120EFBX - 12TB - SATA - 3.5in - 7200 RPM - 256MB Cache
ITCurry #: 60508093 | Article #: WD120EFGX-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Powerful internal HDDs designed for performance, reliability and power efficiency in small to medium NAS environments.
WD Red Plus internal HDDs are designed to handle workloads for power users and small to medium business NAS environments. WD Red Plus drives deliver the speed and capacity required to store, protect and share growing amounts of data in mid-sized RAID-optimized NAS systems with increased power efficiency.
Features | |
HDD capacity | 12 TB |
HDD speed | 7200 RPM |
Storage drive buffer size | 512 MB |
HDD size | 3.5" |
Interface | Serial ATA III |
Type | HDD |
Component for | NAS |
HDD interface transfer rate | 6 Gbit/s |
HDD average transfer rate | 260 MB/s |
Start/stop cycles | 600000 |
Workload rate limit | 180 TB/year |
Mean time between failures (MTBF) | 1000000 h |
Power | |
Power consumption (standby) | 0.3 W |
Power consumption (read) | 8.8 W |
Power consumption (write) | 8.8 W |
Power consumption (idle) | 6.1 W |
Operating voltage | 12 V |
Operational conditions | |
Operating temperature (T-T) | 0 - 65 øC |
Storage temperature (T-T) | -40 - 70 øC |
Weight & dimensions | |
Width | 101.6 mm |
Height | 26.1 mm |
Weight | 750 g |
Packaging data | |
Quantity per pack | 1 pc(s) |
Warranty | |
Base Warranty | Non Non |
