Hard Drive - Ultrastar DC HC510 - 10TB - SAS 12gb/s - 3.5in - 7200rpm - 4Kn Format ISE
ITCurry #: T2792817 | Article #: 0F27402-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
High Capacity – 10TB HDD, drop-in ready for mainstream enterprise
Low Power – 44% more efficient (Watts/TB) than air-filled drives
Most Reliable – Best-in-class reliability rating of 2.5M hours MTBF
Laying the foundation for a worry-free data center, HGST delivers an exceptional capacity hard drive in the industry – Ultrastar He10. Designed to handle workloads up to 550TB per year, the He10 uses PMR technology and is the industry’s first 10TB drive that is drop-in ready for any enterprise-capacity application or environment. Based on field proven, third-generation HelioSeal® technology, it offers the lowest power profile in the industry to help data center architects meet eco-environmental goals and requirements. Targeted at 2.5M hours MTBF, the He10 provides the highest reliability rating available of all HDDs on the market today by building on the successful design of its 8TB and 6TB predecessors. Trust HGST and Ultrastar He10 to deliver more capacity, more efficiency, more reliability and more value to your data center.
| Warranty | |
| Base Warranty | Non Non |
| Features | |
| HDD capacity | 10 TB |
| HDD speed | 7200 RPM |
| Storage drive buffer size | 256 MB |
| HDD size | 3.5" |
| Interface | SAS |
| Type | HDD |
| Component for | Server/workstation |
| HDD interface transfer rate | 12 Gbit/s |
| HDD sustained transfer rate | 237 MiB/s |
| Read seek time | 8 ms |
| Write seek time | 8.6 ms |
| Average latency | 4.16 ms |
| Bytes per sector | 4096 |
| Mean time between failures (MTBF) | 2500000 h |
| Power | |
| Power consumption (typical) | 9.5 W |
| Power consumption (idle) | 5.8 W |
| Operating voltage | 5 / 12 V |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 60 øC |
| Storage temperature (T-T) | -40 - 70 øC |
| Operating vibration | 0.67 G |
| Non-operating vibration | 1.04 G |
| Operating shock | 70 G |
| Non-operating shock | 300 G |
| Weight & dimensions | |
| Width | 101.6 mm |
| Height | 26.1 mm |
| Depth | 147 mm |
| Weight | 660 g |
| Packaging data | |
| Quantity per pack | 1 pc(s) |
| Logistics data | |
| Harmonized System (HS) code | 84717050 |
