Flash Storage Platform 2u24-24 3.84TB SAS 12gb/s 1dw/d
ITCurry #: T2793374 | Article #: 1ES0110-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
The 2U24 Flash Storage Platform is a key element of next generation Software-Defined Storage (SDS) systems. It offers performance advantages as well as flexibility to improve compute-to-capacity ratio by decoupling available storage from CPU resources.
Flash Performance
Depending on the type of SSDs and the number of drives installed, the 2U24 Platform can be configured to deliver the performance you need.
Designed for Enterprise and the Cloud
The 2U24 Flash Storage Platform addresses the demanding storage needs of large enterprises and Cloud service providers. With performance of up to 4.7M IOPS, 23 GB/s and less than 1ms latency, the Platform is the ideal solution for accelerating enterprise workloads such as Database, Virtualization and Scale-Out configurations. The flash platform delivers up to 184TB storage capacity, can be connected to up to six hosts via the 12Gb/s SAS3 interface, and offers enterprise-specific features including:
- Enterprise-class High Availability: hot swappable SSDs, IO Modules, and PSUs
- Fully upgradeable: upgradeable firmware enables drive technology and capacity updates without impacting applications
| Storage | |
| Storage drives installed | Yes |
| Installed storage drive type | SSD |
| Number of storage drives installed | 24 |
| Total installed storage capacity | 92.16 TB |
| Supported storage drive types | SSD |
| Number of storage drives supported | 24 |
| Maximum supported storage capacity | 183.32 TB |
| Storage drive capacity | 3.84 TB |
| Storage drive interface | Serial Attached SCSI (SAS) |
| Storage drive size | 2.5" |
| Data transfer rate | 12 Gbit/s |
| Ports & interfaces | |
| Mini-SAS host port | Yes |
| Design | |
| Chassis type | Rack (2U) |
| Product colour | Silver |
| Redundant fans support | Yes |
| Performance | |
| Device class | Small & Medium Business |
| Power | |
| Power supply unit (PSU) capacity | 600 W |
| AC input voltage | 90-264 V |
| AC input frequency | 50 - 60 Hz |
| Weight & dimensions | |
| Width | 446 mm |
| Depth | 536 mm |
| Height | 87.4 mm |
| Weight | 23.7 kg |
| Logistics data | |
| Harmonized System (HS) code | 84717020 |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 40 øC |
| Operating relative humidity (H-H) | -40 - 60% |
| Warranty | |
| Base Warranty | Non Non |
