Product Information
Liebert PSA 1500VA is a compact line-interactive UPS that offers cost-effective, full featured power protection for small office computer and electronic equipment. Liebert PSA mixes unique features and extraordinary performance. Designed with simple controls for easy operation, it provides up to five minutes of back-up time at full load: more than enough time to save work in process and shut down your system.
Warranty | |
Base Warranty | Non Non |
Features | |
UPS topology | Line-Interactive |
Output power capacity | 1.5 kVA |
Output power | 900 W |
Waveform | Stepwise |
Input operation voltage (min) | 160 V |
Input operation voltage (max) | 287 V |
Input frequency | 50/60 Hz |
Output frequency | 50/60 Hz |
Surge energy rating | 570 J |
Response time | 6 ms |
Number of input phases | 1 |
Number of output phases | 1 |
Power factor | 0.6 |
Output power factor | 0.6 |
Surge protection | Yes |
Audible alarm(s) | Yes |
Ports & interfaces | |
AC outlet types | IEC 320, C13 coupler |
Power plug | C14 coupler |
AC outlets quantity | 8 AC outlet(s) |
USB port | Yes |
USB 2.0 ports quantity | 1 |
Serial ports quantity | 1 |
Battery | |
Battery technology | Sealed Lead Acid (VRLA) |
Battery capacity | 9 VAh |
Battery voltage | 12 V |
Number of batteries supported | 2 |
Typical backup time at full load | 6 min |
Typical backup time at half load | 12 min |
Battery recharge time | 6 h |
Design | |
Form factor | Tower |
Cooling type | Passive |
Product colour | Black |
International Protection (IP) code | IP20 |
Safety | IEC/EN/AS 62040-1-1 |
Certification | CE |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 øC |
Storage temperature (T-T) | -15 - 40 øC |
Operating relative humidity (H-H) | 0 - 90% |
Operating altitude | 0 - 3000 m |
Technical details | |
Compliance certificates | RoHS |
Weight & dimensions | |
Width | 147 mm |
Depth | 360 mm |
Height | 234 mm |
Weight | 12.6 kg |
Package width | 238 mm |
Package depth | 432 mm |
Package height | 352 mm |
Package weight | 12.8 kg |
Logistics data | |
Harmonized System (HS) code | 85078000 |
Other features | |
Battery type | VRLA |
Dimensions (WxDxH) | 147 x 360 x 234 mm |
Nominal input voltage | 230 V |
