Unifi Protect Network Video Recorder Unvr
ITCurry #: N3302520 | Article #: UNVR-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Enterprise network video recorder, can provide up to 30 days of 4K video storage for 15 cameras or Full HD video storage for 50 cameras
The UniFi® NVR is an enterprise network video recorder that integrates an NVR, the UniFi Protect software, and a 4-drive bay. UNVR unifies enterprise-class data protection and scalable storage with simple Plug and Play integration using the intuitive UniFi Protect software. From a desktop computer or mobile device, you can access your surveillance recordings from virtually anywhere using the intuitive graphical user interface. The mobile app is available for iOS and Android-based devices. The drive bays are easily accessed from the front panel, so hard drive mounting and maintenance are simple. Using four 8 TB drives in a RAID 5 configuration, the UNVR can provide up to 30 days of 4k video storage for 15 cameras or Full HD video storage for 50 cameras.
| Performance | |
| Video input channels | 4 channels |
| Storage | |
| HDD capacity | 4 GB |
| RAID support | Yes |
| RAID levels | 5 |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| Ethernet LAN data rates | 1000,10000,100000 Mbit/s |
| Features | |
| Rack mounting | Yes |
| LED indicators | Yes |
| On/off switch | Yes |
| Product colour | Grey |
| Processor | |
| Built-in processor | Yes |
| Processor cores | 4 |
| Processor frequency | 1.7 GHz |
| Power | |
| Power consumption (max) | 100 W |
| Power consumption (typical) | 75 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Output current | 2 A |
| Operational conditions | |
| Operating temperature (T-T) | -5 - 40 øC |
| Warranty | |
| Base Warranty | Non Non |
| Weight & dimensions | |
| Width | 442.4 mm |
| Depth | 325 mm |
| Height | 43.7 mm |
| Weight | 5.11 kg |
| Logistics data | |
| Harmonized System (HS) code | 85219000 |
