U Fiber Nano 24v Passive Black
ITCurry #: N3302418 | Article #: UF-NANO
slide 2 of 5
Price:
64.17
Ex VAT
Shipping:
FREE Shipping on orders over 100€ Ex VAT.
Out of Stock. Contact Us!
Related products
slide 7 to 11 of 14
Product Information
Status Display
The easy-to-read display provides status information: IP address, signal strength, and current throughput.
Power over Ethernet
The Nano G is powered by 24V passive PoE – a single cable to carry both power and data.
Designed for Integration
Up to 128 Nano G devices can be connected to a single GPON port. Supporting GPON links of up to 20 km, the Nano G integrates with the UFiber OLT (coming soon) and third-party OLT devices.
| Design | |
| LED indicators | Yes |
| Certification | CE, FCC, IC |
| Performance | |
| Built-in processor | Yes |
| Processor frequency | 240 MHz |
| Number of processors installed | 1 |
| Internal memory | 128 MB |
| Network | |
| Ethernet LAN data rates | 1000 Mbit/s |
| Data transfer rate | 2.488 Gbit/s |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 1 |
| Power | |
| Power consumption (typical) | 7 W |
| Input voltage | 24 V |
| Input current | 0.3 A |
| Power over Ethernet (PoE) | Yes |
| Weight & dimensions | |
| Weight | 110 g |
| Dimensions (WxDxH) | 77 x 77 x 28 mm |
| Operational conditions | |
| Operating temperature (T-T) | -10 - 45 øC |
| Operating relative humidity (H-H) | 5 - 95% |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Warranty | |
| Base Warranty | Non Non |
