Nanoswitch 4-port Gigabit With Poe Passthrough White
ITCurry #: N3302328 | Article #: N-SW
slide 2 of 5
Price:
32.37
Ex VAT
Shipping:
FREE Shipping on orders over 100€ Ex VAT.
Out of Stock. Contact Us!
Related products
slide 7 to 11 of 14
Product Information
The NanoSwitch is an outdoor, 4-port Gigabit switch with PoE pass-through. It is powered by 24V Passive PoE and provides up to 24W of power on three PoE out ports. The NanoSwitch is designed for outdoor deployment and supports up to 4 Gbps total, non-blocking line rate.
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 4 |
| Basic switching RJ-45 Ethernet ports type | Gigabit Ethernet (10/100/1000) |
| Network | |
| 10G support | No |
| Data transmission | |
| Switching capacity | 4 Gbit/s |
| Design | |
| Rack mounting | No |
| Product colour | White |
| Performance | |
| Built-in processor | Yes |
| Power | |
| Power supply included | No |
| DC input voltage | 24 V |
| Power consumption (typical) | 1.5 W |
| Power over Ethernet (PoE) | |
| Power over Ethernet (PoE) | Yes |
| Power over Ethernet (PoE) ports quantity | 4 |
| Power over Ethernet (PoE) power per port | 24 W |
| Total Power over Ethernet (PoE) budget | 36 W |
| Operational conditions | |
| Operating temperature (T-T) | -30 - 70 øC |
| Operating relative humidity (H-H) | 5 - 95% |
| Weight & dimensions | |
| Width | 93.5 mm |
| Depth | 196.4 mm |
| Height | 32.4 mm |
| Weight | 269 g |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
