Product Information
U6-LR is a high-performance Access Point leveraging advanced WiFi 6 technology to provide powerful wireless coverage to enterprise environments.
It delivers an aggregate radio rate of up to 3.0 Gbps with 5 GHz (4x4 MU-MIMO and OFDMA) and 2.4 GHz 4x4 MIMO radios. The U6-LR seamlessly blends into any environment, and is capable of being mounted in indoor and semi-outdoor environments (IP54 rated).
Features | |
2.4 GHz | Yes |
5 GHz | Yes |
Maximum data transfer rate | 3000 Mbit/s |
Maximum data transfer rate (2.4 GHz) | 600 Mbit/s |
Maximum data transfer rate (5 GHz) | 2400 Mbit/s |
Ethernet LAN data rates | 10,100,1000 Mbit/s |
Number of users | 300 user(s) |
MIMO | Yes |
MIMO type | Multi User MIMO |
VLAN support | Yes |
Quality of Service (QoS) support | Yes |
Security | |
Security algorithms | WPA, WPA-Enterprise, WPA-PSK, WPA2, WPA3 |
Protocols | |
Supported network protocols | 802.11Ax, 802.11Ac, 802.11n, 802.11g, 802.11b, 802.11A, 802.3at, 802.1Q |
Ports & interfaces | |
Ethernet LAN (RJ-45) ports | 1 |
Power | |
Power over Ethernet (PoE) | Yes |
AC input voltage | 44 - 57 V |
Power consumption (max) | 16.5 W |
Design | |
Placement | Ceiling, Wall |
Product colour | White |
Housing material | Plastic |
International Protection (IP) code | IP54 |
Reset button | Yes |
LED indicators | Yes |
Antenna | |
Antenna type | Internal |
Antenna gain level (max) | 5.5 dBi |
Performance | |
Built-in processor | Yes |
Processor frequency | 1.35 MHz |
Certificates | |
Certification | CE, FCC, IC |
Weight & dimensions | |
Width | 220 mm |
Depth | 48 mm |
Height | 220 mm |
Weight | 800 g |
Packaging content | |
Quantity per pack | 1 pc(s) |
Mounting kit | Yes |
Operational conditions | |
Operating relative humidity (H-H) | 5 - 95% |
Operating temperature (T-T) | -30 - 60 øC |
Logistics data | |
Harmonized System (HS) code | 85176990 |
Warranty | |
Base Warranty | Non Non |
