Network Camera Insight S345 Vigi 4 Mpix Full-color Dome With 2.8mm Lens

ITCurry #: P6043983 | Article #: INSIGHT S345(2.8MM)
Price:
175.60 Ex VAT
Shipping:
FREE Shipping.
Out of Stock. Contact Us!
Email us for assistance

Related products

slide 7 to 11 of 14

Product Information

People & Vehicle Analytics
Search and filter to people or vehicle of interest based on many different attributes, making post-event search faster and easier.

Human & Vehicle Classification
Distinguish humans and vehicles from other objects and receive more accurate event notifications.

True WDR: By analyzing and blending different exposures, True WDR ensures both bright and dark areas remain properly exposed, delivering a well-balanced and natural-looking image even in environments with high-contrast lighting.?

Smart IR: Smart IR dynamically adjusts infrared lighting to prevent overexposure and glare, improve visibility at different distances, and ensure clearer footage.

3D DNR: 3D DNR is a noise reduction technology that analyzes image data across frames to selectively reduce noise while preserving important details.

White Balance: White Balance ensures that white appears neutral in an image, regardless of the lighting conditions.

Efficient H.265+ Compression Technology
H.265+ reduces the required bandwidth and storage space for videos while maintaining excellent image quality. It saves 57.5% and 15% more storage space compared to H.264 and H.265, respectively.

Performance
Type IP security camera
Placement supported Outdoor
Connectivity technology Wired
Maximum operating distance 64 m
Wide Dynamic Range (WDR) Yes
Day/night mode Yes
Infrared (IR) cut-off filter Yes
Remote viewing Yes
Dynamic range 120 dB
Design
Form factor Bullet
Mounting type Wall
Product colour White
Housing material Metal
Protection features Waterproof
International Protection (IP) code IP67
Weatherproof Yes
Camera
Minimum illumination 0 lx
Lens viewing angle, horizontal 100ø
Lens viewing angle, vertical 54ø
Lens viewing angle, diagonal 118ø
Tilt angle range 0 - 90ø
Camera shutter speed 1/3 to 1/10000
Image sensor
Optical sensor size 25.4 / 2.7 mm (1 / 2.7")
Progressive scan Yes
Sensor type CMOS
Lens system
Detect distance 64 m
Observe distance 27 m
Recognize distance 13 m
Maximum aperture number 1.6
Identify distance 6 m
Fixed focal length 2.8 mm
Night vision
Night vision Yes
LED type IR/White
Video
Maximum resolution 2688 x 1520 pixels
Total megapixels 4 MP
Video compression formats H.264, H.264+, H.265, H.265+
Supported graphics resolutions 1280 x 720 (HD 720), 1920 x 1080 (HD 1080), 2048 x 1280, 2304 x 1296, 2560 x 1440, 2688 x 1520
Video recording Yes
Image quality adjustment Brightness, Contrast, Mirror, Saturation, Sharpness
Bit rate control Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
Bit rate Main Stream: 256 Kbps to 6 Mbps, Sub-Stream: 64 Kbps to 512 Kbps
Back Light Compensation (BLC) Yes
Highlight Compensation (HLC) Yes
Digital Wide Dynamic Range (DWDR) Yes
Audio
Built-in speaker(s) Yes
Audio system 2-way
Audio input channels 1 channels
Audio output channels 1 channels
Audio formats supported G.711 A-law
Sample rate 8 kHz
Built-in microphone Yes
Number of microphones 1
Bit rate range 0 - 64 Kbit/s
Network
Ethernet LAN Yes
Networking standards IEEE 802.3af, IEEE 802.3at
Supported network protocols TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
Wi-Fi No
Bluetooth No
Live view Yes
Storage
Compatible memory cards MicroSD (TransFlash)
Maximum memory card size 512 GB
Ports & interfaces
Ethernet LAN (RJ-45) ports 1
DC-in jack Yes
Security
Built-in siren Yes
Password protection Yes
Video motion detection Yes
IP address filtering Yes
HTTPS encryption Yes
Alert notification type Push notification
Motion sensor Yes
Mirror Yes
Human and vehicle targets classification Yes
Digest authentication Yes
Management features
Web-based management Yes
Web browser Yes
Cloud-managed Yes
Reset button Yes
Power
Power source type DC, PoE
Power consumption (Power over Ethernet (PoE)) 10.7 W
DC output voltage 12
Operational conditions
Operating temperature (T-T) -30 - 60 øC
Storage temperature (T-T) -40 - 60 øC
Operating relative humidity (H-H) 0 - 95%
Storage relative humidity (H-H) 0 - 95%
Weight & dimensions
Width 74 mm
Height 74 mm
Length 184 mm
Weight 525 g
Packaging content
Number of cameras 1
Mounting kit Yes
Screws included Yes
Drilling template included Yes
Manual Yes
Warranty
Base Warranty Non Non
