Product Information
Easily add 24 additional drive bays to Synology FlashStation or RackStation1. Supporting 2.5” SAS/SATA drives, the RX2417sas is a flexible solution supporting on-the-fly volume expansion or serving as a local backup destination.
Maximum reliability design
Dual power supplies ensure continuous service uptime. Easily replace defective drives with the hot swappable drive trays. Experience fast and secure rack cabinet installation with the optional sliding rail kit RKS1317.
| Storage | |
| Storage drives installed | No |
| Installed storage drive type | No |
| Supported storage drive types | HDD & SSD |
| Number of storage drives supported | 24 |
| Storage drive interface | Serial Attached SCSI (SAS) |
| Storage drive size | 2.5" |
| Hot-swap drive bays | Yes |
| Ports & interfaces | |
| SAS host port | Yes |
| Design | |
| Device class | Large Enterprise Business |
| Chassis type | Rack (2U) |
| Product colour | Black |
| LED indicators | Yes |
| Number of fans | 4 fan(s) |
| Noise level | 60.8 dB |
| Certification | FCC A CE A BSMI A |
| Power | |
| Power supply unit (PSU) capacity | 500 W |
| Number of power supply units | 2 |
| Power consumption (typical) | 201.6 W |
| AC input voltage | 100-240 V |
| AC input frequency | 50 - 60 Hz |
| Warranty | |
| Base Warranty | Non Non |
| Weight & dimensions | |
| Width | 482 mm |
| Depth | 724 mm |
| Height | 88 mm |
| Weight | 16.6 kg |
| Operational conditions | |
| Operating temperature (T-T) | 5 - 35 øC |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage temperature (T-T) | -20 - 60 øC |
| Other features | |
| Compliance certificates | RoHS |
| Logistics data | |
| Harmonized System (HS) code | 84717020 |
Expansion Unit Rx2417SAS 24-bay 2.5in Sas/ SATA Expansion
2577.49
