Deep Learning Nvr Dva3221 - 4 Bay
ITCurry #: M6054111 | Article #: DVA3221-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Smarter video surveillance
Synology Deep Learning NVR combines powerful video management system features with AI-powered analytics. Generate real-time statistics and alerts to act on issues immediately.
Actionable insights
Video footage is transformed into actionable insights with advanced deep learning-based analytics, enhancing security without requiring additional personnel.
On-prem recording and analytics
Powered by Synology DSM, footage is kept on the device, with options to flexibly backup or archive to other devices and locations.
Comprehensive VMS platform
DVA3221 is an all-in-one NVR solution, combining video recording, analysis, and advanced video management.
Action rules
Set up security policies so that when a condition is met, corresponding actions can be triggered automatically, reducing time and effort needed for manual interventions.
Easy to setup and operate
Designed to be simple for both administrators and operators, adding and managing cameras, navigating between live feeds and recordings, and configuring permissions and backup tasks are all straightforward. Built ontop of Synology DSM, graphical interfaces simplify complicated tasks, while still retaining flexibility.
Cross-platform, internet-optional
Access your surveillance system on any system through a browser, our PC/Mac/Linux client, or through mobile apps, both with or without internet access.
API ready
Comprehensive documentation available to third-party developers looking to integrate their products or applications with Surveillance Station.
One-stop support
An integrated system means a single point of support for both the hardware and software solution, simplifying setup and maintenance efforts needed.
| Performance | |
| Video input channels | 32 channels |
| Internal memory | 8000 MB |
| Internal memory type | DDR4 |
| Number of users | 2048 user(s) |
| Video formats supported | H.264, H.265, MPEG4 |
| Languages support | Multi |
| PTZ control | Y |
| Number of fans | 1 fan(s) |
| Wireless LAN features | |
| Wi-Fi | N |
| Storage | |
| Number of HDDs supported | 4 |
| Maximum storage capacity | 108 TB |
| HDD interface | Serial ATA |
| HDD size | 2.5/3.5" |
| RAID support | Y |
| RAID levels | 0, 1, 5, 6, 10, JBOD |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 4 |
| Ethernet LAN data rates | 1000 Mbit/s |
| Ethernet WAN | Y |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 3 |
| eSATA ports quantity | 2 |
| eSATA | Y |
| COM ports quantity | 1 |
| Features | |
| Brand compatibility | Synology |
| LED indicators | Y |
| Reset button | Y |
| On/off switch | Y |
| Product colour | Black |
| Processor | |
| Built-in processor | Y |
| Processor cores | 4 |
| Processor frequency | 2.1 GHz |
| Display | |
| Built-in display | N |
| Power | |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| System requirements | |
| Windows operating systems supported | Y |
| Mac compatibility | Y |
| Browser supported | Chrome, Firefox, Edge, Internet Explorer 10 onwards, Safari 10 onwards |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 øC |
| Operating relative humidity (H-H) | 5 - 95% |
| Storage temperature (T-T) | -20 - 60 øC |
| Weight & dimensions | |
| Width | 250 mm |
| Depth | 237 mm |
| Height | 166 mm |
| Weight | 4.92 kg |
| Packaging content | |
| Cables included | AC, LAN (RJ-45) |
| Logistics data | |
| Harmonized System (HS) code | 85219000 |
| Warranty | |
| Base Warranty | Non Non |
