Portable Docking Station | For Windows® & Mac | Thunderbolt™ 3 Compatible
This USB-C VGA multiport adapter combines the capability of two single-function adapters, a USB-C video adapter and USB-C to USB adapter, into a portable docking station for your laptop. You can instantly connect to a VGA display and a USB 3.0 (Type-A) device, while also powering and charging your laptop using the same adapter.
Mobile Multitasking
With a secondary display connected to your laptop, you can multitask faster and easier. The USB-C adapter’s VGA video output lets you create a dual-screen workstation comprised of your laptop’s display and an additional VGA monitor or projector, in a boardroom or other professional environment.
Powers and Charges Your Laptop
With USB Power Delivery, you can power and charge your laptop by simply connecting the multiport adapter to your laptop’s USB Type-C port, then connecting a USB Type-C power adapter.
Universal Compatibility
The USB-C multiport adapter features a built-in USB-C cable and works with USB-C equipped MacBook, Chromebook™ and Windows laptops that support DisplayPort (DP) Alt Mode and USB Power Delivery.
Rugged and Portable
Compact, lightweight design and rugged construction lets you take this USB-C video adapter anywhere you take your laptop.
The StarTech.com Advantage for Docking Stations
• Maximum compatibility - StarTech.com has a docking station to fit every operating system, laptop brand, and connectivity need
•
Get more done faster - More ports and more displays maximize end user connectivity and productivity
•
Quick installation - eliminate deployment headaches that waste time and frustrate end users
•
IT Grade quality - trusted by IT pros around the world for our rigorous in-house product testing, robust compliance, and lifetime multilingual technical support
The CDP2VGAUACP is backed by a StarTech.com 3-year warranty and free lifetime technical support.
The StarTech.com Advantage
| Ports & interfaces | |
| Connectivity technology | Wired |
| Host interface | USB 3.2 Gen 1 (3.1 Gen 1) Type-C |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 1 |
| USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity | 1 |
| USB Power Delivery | Yes |
| USB Power Delivery up to | 60 W |
| VGA (D-Sub) ports quantity | 1 |
| Microphone in | No |
| Network | |
| Ethernet LAN | No |
| Performance | |
| Card reader integrated | No |
| Data transfer rate | 5 Gbit/s |
| Maximum analog resolution | 2048 x 1280 pixels |
| Product colour | Black |
| UASP support | Yes |
| Housing material | Plastic |
| Brand compatibility | Any brand |
| Power | |
| Power source type | USB |
| Warranty | |
| Base Warranty | Non Non |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 45 øC |
| Storage temperature (T-T) | -10 - 70 øC |
| Operating relative humidity (H-H) | 5 - 90% |
| Sustainability | |
| Sustainability compliance | Yes |
| Weight & dimensions | |
| Width | 40 mm |
| Depth | 80 mm |
| Height | 15 mm |
| Weight | 39 g |
| Packaging data | |
| Package width | 145 mm |
| Package depth | 171 mm |
| Package height | 34 mm |
| Package weight | 109 g |
| Technical details | |
| Compliance certificates | CE, RoHS |
| Logistics data | |
| Products per master (outer) case | 60 pc(s) |
| Master (outer) case width | 338 mm |
| Master (outer) case length | 531 mm |
| Master (outer) case height | 315 mm |
| Harmonized System (HS) code | 84733020 |
| Other features | |
| Cable length | 0.14 m |
| Chipset | VIA/VLI - VL100, VIA/VLI - VL210, NXP - PTN3355 |
