Product Information
Unforgettable images to match the largest creative ambitions
The ZRD-C12A modular display cabinet combines advanced Micro LED technology with powerful processor "X1™ for Crystal LED" to create bigger, bolder, more attention-grabbing visual experiences.
Offering spectacular 1,000,000:1 contrast and a high brightness of 800 cd/m2, the ZRD-C12A is ideal for presenting immersive HDR content in a wide range of environments including corporate lobbies, showrooms, boardrooms, museums, galleries and other public spaces. Cutting-edge picture processing technologies ensure immersive large-scale images with industry leading clarity and colour.
The ZRD-C12A features a resolution of 480 x 270 dots, with a pixel pitch of 1.26 mm.
The borderless design of each energy-efficient Micro LED panel allows multiple ZRD-C12A cabinets to be tiled seamlessly, creating super-size high resolution displays with virtually any dimensions or aspect ratio – and no bezels or visible gaps. The slim, light Micro LED panels are easy to install and maintain without requiring special skills or complex equipment.
| Supplier features | |
| Response time | 608 mm |
| Display | |
| Display technology | MicroLED |
| Pixel pitch | 1.26 x 1.26 mm |
| Display brightness | 800 cd/mý |
| Contrast ratio (typical) | 1000000:1 |
| High Dynamic Range (HDR) supported | Y |
| Viewing angle, horizontal | 160ø |
| Viewing angle, vertical | 160ø |
| Colour gamut | 97% |
| Colour depth | 22 bit |
| Design | |
| Placement supported | Indoor |
| Orientation | Landscape |
| Product colour | Black |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 2 |
| Power | |
| Power consumption (typical) | 64 W |
| Power consumption (max) | 157 W |
| AC input voltage | 100 - 240 V |
| AC input frequency | 50 - 60 Hz |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 40 øC |
| Storage temperature (T-T) | -20 - 60 øC |
| Operating relative humidity (H-H) | 20 - 80% |
| Storage relative humidity (H-H) | 20 - 80% |
| Technical details | |
| Pallet net height | 85 cm |
| Pallet net length | 120 cm |
| Pallet net width | 100 cm |
| Products per pallet | 8 pc(s) |
| Weight & dimensions | |
| Depth | 76 mm |
| Height | 342 mm |
| Weight | 9.5 kg |
| Warranty | |
| Base Warranty | Non Non |
