Compact Camera Srg-xb25 60mpix 12x Optical Zoom Box-style Remote White

ITCurry #: 5320Y205 | Article #: SRG-XB25W
Price:
2395.00 Ex VAT
Shipping:
FREE Shipping.
Out of Stock. Contact Us!
Email us for assistance

Related products

slide 7 to 11 of 14

Product Information

Stream crisp, detail-packed 4K 60p video with this high quality remote camera that features a powerful 25x optical zoom lens for frame-filling close-ups in larger venues.

The SRG-XB25 high-zoom BOX camera draws on decades of Sony’s professional imaging know-how to suit a wide range of content creation applications. It’s ideal for capturing and streaming impressive 4K pictures in environments including seminar rooms, lecture theatres, virtual production studios, government/parliament buildings and houses of worship. The cost-effective SRG-XB25 is particularly appealing for multi-camera shooting set-ups, where high quality images are required without the need for a team of dedicated camera operators. The integrated lens with powerful 25x optical zoom captures frame-filling close-ups of speakers and presenters, even when the camera’s installed at the back or larger auditoriums and public venues. The SRG-XB25 fits seamlessly into all-IP production environments, with a single Ethernet cable carrying power, streaming video and camera control signals. Ideal for lecture capture applications, the SRG-XB25 partners seamlessly with the REA-C1000 Edge Analytics Appliance. For example, the camera’s powerful 25x zoom captures the speaker’s gestures and handwriting in large classrooms or teaching spaces, allowing REA-C1000 to deliver what the customer requires.

Robust, stylish and compact

Measuring just 70.9 x 80.1 x 178.3 mm and weighing 872 g, the SRG-XB25 can be readily integrated into any environment. Upper and lower tripod mounts increase installation flexibility. Rear panel guards assure extra robustness, and the large, easy-to-read tally lamp is useful in multiple camera set-ups.

Powerful 25x optical zoom

The integrated autofocus lens with 25x optical zoom plus additional digital zoom assures ultra-clear, powerful close-ups of presenters or audience members.

Easy IP connectivity, single-cable installation

Camera control, PoE and streaming video output are carried over a single Ethernet cable, reducing installation costs and simplifying integration in space-restricted or hard-to-reach locations. Full IP integration includes support for Real Time Streaming Protocol (RTSP) and Real Time Messaging Protocol (RTMP). Support for NDI |HX is also available via an optional licence.

High quality 4K 60p images

The camera’s 1/2.5-type Exmor R CMOS sensor captures smooth, crisply detailed 4K 60p video with excellent low-light sensitivity.

Broadcast-style tally light

The camera-mounted tally light gives visual confirmation to the lecturer or presenter when the camera is active. The horizontal bar-style light is easily visible to both performer/presenter and director.

Audio input

Connect an external microphone or line-level source to capture clear pictures plus sound in lecture theatres and meeting rooms or on reality TV shows.

Performance
Type IP security camera
Placement supported Indoor
Connectivity technology Wired
Design
Form factor Box
Product colour White
Camera
Minimum illumination 1 lx
Lens viewing angle, horizontal 68ø
Camera shutter speed 1 - 1/10000 s
Image sensor
Number of sensors 1
Optical sensor size 25.4 / 1.25 mm (1 / 1.25")
Sensor type CMOS
Lens system
Zoom capability Yes
Optical zoom 25x
Digital zoom 4x
Number of lenses 1
Focal length range 4.8 - 120.5 mm
Closest focusing distance 1.5 m
Video
Maximum resolution 3840 x 2160 pixels
Total megapixels 8.5 MP
Video formats supported H.264, H.265
Supported video modes 480p, 720p, 1080p, 3840p
Frame rate 59.94 fps
Video streaming Yes
Audio
Audio formats supported AAC
Network
Ethernet LAN Yes
Networking standards IEEE 802.3af
Streaming method Multicast
Ports & interfaces
Ethernet LAN (RJ-45) ports 1
RS-232 ports 1
HDMI ports quantity 1
DC-in jack Yes
Power
Power source type DC, PoE
DC output voltage 12
Weight & dimensions
Width 70.9 mm
Depth 178.3 mm
Height 80.1 mm
Weight 872 g
Packaging content
Number of cameras 1
Logistics data
Harmonized System (HS) code 85258900
Warranty
Base Warranty Non Non
