Product Information
Powerful 1.3-litre PC with Intel "Tiger Lake-U" processor supports four Ultra HD displays
This space-saving Slim PC integrates an energy-efficient Gen 11 Intel ULV processor "Tiger Lake-U" and supports no less than four Ultra HD displays at 60 Hz frame rate via HDMI 2.0b. Its slim metal chassis with a VESA mount included, versatile connectivity and reliable operation in ambient temperatures of up to 50 °C degrees, make it ideal for vertical applications such as Digital Signage, Kiosk, Surveillance, Control Room, Gambling Machines, Healthcare and Industry.
Processor | |
Built-in processor | Y |
Processor manufacturer | Intel |
Processor family | Intel© Pentium© Gold |
Processor model | 7505 |
Processor cores | 2 |
Processor threads | 4 |
Processor lithography | 10 nm |
Processor boost frequency | 3.5 GHz |
Processor cache | 4 MB |
CPU configuration (max) | 1 |
Memory | |
Memory slots type | SO-DIMM |
Number of memory slots | 2 |
Maximum internal memory | 64 GB |
Supported memory clock speeds | 3200 MHz |
Supported memory types | DDR4-SDRAM |
Memory channels | Dual-channel |
Memory voltage | 1.2 V |
Storage | |
Supported storage drive types | HDD & SSD |
Storage drive sizes supported | 2.5,M.2 |
Storage drive interface | PCI Express, Serial ATA III |
Number of storage drives supported | 2 |
Card reader integrated | Y |
Compatible memory cards | SD, SDHC, SDXC |
Graphics | |
On-board graphics card | Y |
Graphics card family | Intel |
On-board graphics card model | Intel© UHD Graphics |
Maximum resolution | 4096 x 2304 pixels |
Audio | |
Built-in speaker(s) | N |
Network | |
Ethernet LAN | Y |
Wi-Fi | N |
LAN controller | Intel© I211 |
Ports & interfaces | |
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity | 4 |
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity | 4 |
HDMI ports quantity | 4 |
HDMI version | 2.0b |
Microphone in | Y |
Headphone outputs | 1 |
Ethernet LAN (RJ-45) ports | 2 |
Serial ports quantity | 2 |
DC-in jack | Y |
Expansion slots | |
PCI Express slots version | 4.0 |
Number of M.2 (M) slots | 1 |
Design | |
Chassis type | 1.35L sized PC |
Product colour | Black |
Cooling type | Active |
LED indicators | HDD, Power |
Housing material | Metal |
Cable lock slot | Y |
Cable lock slot type | Kensington |
VESA mounting | Y |
Product type | Mini PC barebone |
Performance | |
Motherboard chipset | Intel SoC |
Number of processors supported | 1 |
BIOS type | UEFI AMI |
Trusted Platform Module (TPM) version | 2.0 |
Audio output channels | 5.1 channels |
Windows operating systems supported | Windows 10, Windows 11 |
Linux operating systems supported | Y |
Operating system installed | N |
Processor special features | |
Embedded options available | N |
Intel Virtualization Technology for Directed I/O (VT-d) | Y |
Intel VT-x with Extended Page Tables (EPT) | Y |
Idle States | Y |
Intel Trusted Execution Technology | N |
Intel Stable Image Platform Program (SIPP) | N |
Intel Virtualization Technology (VT-x) | Y |
Logistics data | |
Country of origin | China |
Harmonized System (HS) code | 84713000 |
Power | |
Power supply type | External AC adapter |
Power supply | 90 W |
Number of power supply units | 1 |
AC input voltage | 100 - 240 V |
AC input frequency | 50 - 60 Hz |
AC adapter output voltage | 19 V |
AC adapter output current | 4.74 A |
Operational conditions | |
Operating temperature (T-T) | 0 - 50 øC |
Operating relative humidity (H-H) | 10 - 90% |
Weight & dimensions | |
Width | 190 mm |
Depth | 165 mm |
Height | 43 mm |
Weight | 1.3 kg |
Package weight | 2.1 kg |
Packaging content | |
Power cord included | Y |
AC adapter included | Y |
Drivers included | Y |
Warranty | |
Base Warranty | Non Non |
