Product Information
With pure sine wave output waveform, Mantis II 750/1K/1.5K Series offers perfect power protection for sensitive equipment. It provides comprehensive LCD display for users to monitor the power status. With powerful protection, it secures your data loss from power failure, surge, and sags.
- 750VA/1000VA/1500VA line interactive sine wave UPS
- Ideal for network equipment, NAS, ATM and Kiosk
- Cost-efficient solution without compromising the performance
- High conversion efficiency (>95%) results in energy saving
- Automatic boost and fade voltage regulation
- LCD graphic display gives comprehensive information at a glance
- HID-compatible USB port
- Easy battery replacement
- Compact design and easy install
- CE and UL applicable
Features | |
UPS topology | Line-Interactive |
Output power capacity | 1 kVA |
Output power | 700 W |
Waveform | Sine |
Input operation voltage (min) | 176 V |
Input operation voltage (max) | 288 V |
Input frequency | 55/65 Hz |
Output voltage regulation | ñ10% |
Efficiency | 95% |
Power factor | 0.7 |
Noise level | 55 dB |
Power protection features | Battery discharge, Overcharge, Overload |
Audible alarm(s) | Yes |
Audible alarm modes | Battery replacement |
Ports & interfaces | |
USB 2.0 ports quantity | 1 |
Ethernet LAN (RJ-45) ports | 2 |
Battery | |
Battery capacity | 9 Ah |
Battery voltage | 12 V |
Number of batteries supported | 2 |
Typical backup time at full load | 40 min |
Battery recharge time | 3 h |
Hot-swap battery | Yes |
Design | |
Form factor | Tower |
Product colour | Black |
Display type | LCD |
Certification | CE, UL |
Operational conditions | |
Operating temperature (T-T) | 0 - 40 øC |
Operating relative humidity (H-H) | 0 - 90% |
Weight & dimensions | |
Width | 150 mm |
Depth | 340 mm |
Height | 209 mm |
Weight | 11.5 kg |
Warranty | |
Base Warranty | Non Non |
Logistics data | |
Harmonized System (HS) code | 85078000 |
