XS508M - Unmanaged Switch 8-Port 5-Speed 10-Gigabit/Multi-Gigabit

ITCurry #: 20325230 | Article #: XS508M-100EUS
Price:
387.40 Ex VAT
Shipping:
FREE Shipping.
Out of Stock. Contact Us!
Email us for assistance
Key Specifications
  • Model
    ProSAFE XS508M
  • Port Count
    7
  • Uplink / media
    10GbE Copper
  • Mounting
    Rack
  • View All Specs

Related products

slide 6 to 10 of 15

Product Information

The ProSAFE XS508M is equipped with 5-speed copper Ethernet ports: FastEthernet, 1-Gigabit 2.5-Gigabit 5-Gigabit and 10-Gigabit. There is also 1 SFP + fiber optic port with speeds of 1-Gigabit and 10-Gigabit. Each port automatically detects which speed is required for the connected device and ensures the correct speed. Unlike ordinary 10-Gigabit switches that provide only 1-Gigabit connectivity for any device that requires less than 10 Gigabit, the XS508M gives the exact speed required without having to downgrade. NETGEAR 5-speed switch ports can be connected using standard CAT5e Ethernet cables without the need to upgrade to CAT6 cabling. This saves you on cabling costs and reduces your hassle.

General
Model ProSAFE XS508M
Type Fixed Port
Technical Features
Port Count 7
Other Ports 1
Management Unmanaged
Routing/Switching Layer 2
Uplink Speed/Media 10GbE Copper
High Availability None
Management Features MAC address table : 2000 entries
Routing/Switching Capacity 160 Gbit/s
Ports/Interfaces sfp,RJ-45
Protocols/Networks IEEE 802.1p,IEEE 802.3,IEEE 802.3ab,IEEE 802.3ae,IEEE 802.3an,IEEE 802.3aq,IEEE 802.3az,IEEE 802.3bz,IEEE 802.3u,IEEE 802.3x,IEEE 802.3z
LEDs Yes
Form Factor
Mounting Rack
Other Factors Colour of product : Grey, Silver
Power and Operating Requirements
Power Consumption 21.31 W
Input Voltage 100 - 240 V
Input Frequency 50 - 60HZ
Environmental Specifications Operating temperature (T-T) : 0 - 50 øC
Storage temperature (T-T) : -20 - 70 øC
Operating relative humidity (H-H) : 0 - 95%
Storage relative humidity (H-H) : 0 - 95%
Dimensions and Weight
Width 328 mm (12.91 inches)
Height 43.2 mm (1.70 inches)
Depth 169 mm (6.65 inches)
Weight 1.49 kg (3.28 lb)
Warranty
Base Warranty Non Non
