Dual Band 802.11ac Wireless Access Point WAC104
ITCurry #: 20325150 | Article #: WAC104-100PES-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
The NETGEAR® Dual Band 802.11ac Wireless Access Point (AP) delivers high performance wireless connectivity for Small Office and Home (SOHO) deployments and supports dual band concurrent operation at 2.4GHz and 5GHz with combined throughput of 1.2 Gbps (300Mbps at 2.4GHz and 867Mbps at 5GHz). The WAC104 Wireless 802.11ac Access Point provides standalone configuration with easy setup for a reliable, high-performance, and affordable wireless solution.
Easy to Configure
- Simple setup in minutes with intuitive. Graphical User Interface (GUI)
- Comprehensive monitoring with web-based access
High performance and superior coverage
- Dual band concurrent operation between 2.4GHz and 5GHz frequency ranges
- Maximize coverage for optimal deployment for SOHO
Comprehensive security
- Supports wireless security features (WPA, WPA2)
- MAC based Access Control List to protect against intruders
Interoperate with both new and legacy clients
- Support latest 802.11ac wireless clients to achieve maximum speed
- Backward compatible to allow legacy devices to connect at their fastest speed
| Warranty | |
| Base Warranty | Non Non |
| Features | |
| 2.4 GHz | Y |
| 5 GHz | Y |
| Maximum data transfer rate | 1167 Mbit/s |
| Maximum data transfer rate (2.4 GHz) | 300 Mbit/s |
| Maximum data transfer rate (5 GHz) | 867 Mbit/s |
| Ethernet LAN data rates | 10,100,1000 Mbit/s |
| Frequency band | 2.4/5 GHz |
| Networking standards | IEEE 802.11a, IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Number of users | 128 user(s) |
| Auto MDI/MDI-X | Y |
| Quality of Service (QoS) support | Y |
| Security | |
| Security algorithms | WEP, WPA, WPA-PSK, WPA2, WPA2-PSK |
| MAC address filtering | Y |
| Access Control List (ACL) | Y |
| Management features | |
| Web-based management | Y |
| Ports & interfaces | |
| Ethernet LAN (RJ-45) ports | 4 |
| DC-in jack | Y |
| Power | |
| AC input voltage | 12 V |
| Input current | 1.5 A |
| Power consumption (typical) | 18 W |
| Design | |
| Placement | Table, Wall |
| Product colour | Black |
| LED indicators | Activity, LAN, Power, WLAN, WPS |
| Internal | N |
| Antenna | |
| Antenna type | External |
| Antennas quantity | 1 |
| Antenna gain level (max) | 3 dBi |
| Operational conditions | |
| Operating relative humidity (H-H) | 10 - 0% |
| Operating temperature (T-T) | 0 - 40 øC |
| Storage temperature (T-T) | -20 - 70 øC |
| Storage relative humidity (H-H) | 5 - 95% |
| Technical details | |
| Harmonized System (HS) code | 85176990 |
| Weight & dimensions | |
| Width | 181.4 mm |
| Depth | 239.7 mm |
| Height | 40.6 mm |
| Weight | 385 g |
| Packaging data | |
| AC adapter included | Y |
| Cables included | LAN (RJ-45) |
| Quick start guide | Y |
