Touch Monitor - Infinityboard 2.1 Ql - 86in
ITCurry #: 38909160 | Article #: 40001445-
ScreenMemoryWeightProcessorHard DiskSSDScreenResolutionConnectivityMemoryCaseOSScreenTypeSpeed BlackSpeed ColourModelProcessor SpeedForm FactorInternal / ExternalPort CountUplink / mediaMounting
- View All Specs
Bundles
Related products
Product Information
Your meeting room companion
NEC’s InfinityBoard is a powerful and scalable workspace that is designed to fit any meeting scenario. Brainstorming, reviewing, video conferencing or collaborating, whatever the objectives of your meeting, the InfinityBoard is the modular solution that’s here to help create your ideal meeting space.
Designed to ‘just work’, the InfinityBoard supports any scenario – from multiple presenters to large groups with remote participation. In virtual workspaces, collaboration lifts to a new level and interactive meetings boost group work efficiency.
The InfinityBoard comes with an ultra-high definition InGlass™ touch display and two passive pens. Its design also includes an ultra-wide angle Huddly IQ video conferencing camera and high-end conference speakers. The combination of an open platform slot-in PC and Windows 10 Professional allows to tailor the solution according to the customers' requirements without restriction to any particular software, video conferencing app or infrastructure. Quicklaunch™ is a simple and secure meeting room interface that provides multi-platform integration to transform the InfinityBoard into a one-click meeting space.
| Performance | |
| Bluetooth | Y |
| Bluetooth version | 4.2 |
| Product colour | Black |
| Product type | Group video conferencing system |
| Wall mountable | Y |
| Video | |
| HD type | Full HD |
| Supported video modes | 1080p |
| Supported graphics resolutions | 1920 x 1080 (HD 1080) |
| Maximum frame rate | 30 fps |
| Aspect ratio | 16:9 |
| Video formats supported | FLV, MOV, MP4, MPG, WMV |
| Resolution at capture speed | 1920x1080@30fps |
| Image formats supported | JPG, PNG |
| Audio | |
| Frequency range | 70 - 15000 Hz |
| Line-out impedance | 8 O |
| RMS rated power | 40 W |
| Audio formats supported | MP3, WAV |
| Memory | |
| Internal memory | 16384 MB |
| Internal memory type | DDR4 |
| Storage media type | SSD |
| Total storage capacity | 256 GB |
| Memory card slot(s) | Y |
| Compatible memory cards | MicroSD (TransFlash), MicroSDHC |
| Ports & interfaces | |
| HDMI ports quantity | 3 |
| USB connector type | USB Type-A, USB Type-B |
| USB 2.0 ports quantity | 4 |
| Ethernet LAN (RJ-45) ports | 2 |
| Fast Ethernet (copper) ports quantity | 2 |
| Headphone outputs | 1 |
| Serial interface type | RS-232 |
| RS-232 ports | 1 |
| Network | |
| Ethernet LAN | Y |
| Ethernet LAN data rates | 100 Mbit/s |
| Wi-Fi | Y |
| Wi-Fi standards | Wi-Fi 5 (802.11ac) |
| Camera | |
| Digital zoom | 3x |
| Horizontal field of view | 120ø |
| Vertical field of view | 90ø |
| Diagonal field of view | 150ø |
| Display | |
| Built-in display | Y |
| Display | IPS |
| Display diagonal | 2.18 m (86") |
| Display resolution | 3840 x 2160 pixels |
| Contrast ratio (typical) | 1200:1 |
| Touchscreen | Y |
| Viewing angle, horizontal | 178ø |
| Viewing angle, vertical | 178ø |
| Display brightness | 500 cd/mý |
| Colour depth | 10 bit |
| Anti-glare screen | Y |
| Logistics data | |
| Harmonized System (HS) code | 85176990 |
| Computer system | |
| VESA mounting | Y |
| Windows operating systems supported | Windows 10, Windows 7, Windows 8, Windows Vista, Windows XP |
| Mac operating systems supported | Y |
| Mobile operating systems supported | Y |
| Operational conditions | |
| Operating temperature (T-T) | 0 - 35 øC |
| Operating relative humidity (H-H) | 20 - 80% |
| Power | |
| Power consumption (max) | 242 W |
| Weight & dimensions | |
| Width | 2192 mm |
| Depth | 86 mm |
| Height | 1142 mm |
| Weight | 91.7 kg |
| Package width | 2157 mm |
| Package depth | 1290 mm |
| Package height | 320 mm |
| Package weight | 98 kg |
| Packaging content | |
| Cables included | AC, DisplayPort, USB |
| Remote control included | Y |
| Camera included | Y |
| Manual | Y |
| Warranty | |
| Base Warranty | Non Non |
